Akumuliatorių įkroviklis, 12V 6A

Trumpai apie prekę

Prekė: Akumuliatorių įkroviklis, 12V 6A. Kategorija: Baterijų įkrovikliai.

• Gamintojas: Foxsur
• Modelis: Prostownik Mikroprocesorowy 12V 6A

Meet the modern microprocessor rectifier 12V 6A – a smart device that will take care of the battery in your car, motorcycle or agricultural machine.

Thanks to automatic control, repair of deeply discharged batteries and special operating modes (car, motorcycle, Start-Stop), the RJ-C 120501A rectifier ensures safe, fast and efficient charging.

The device automatically adjusts the voltage depending on the ambient temperature (winter/summer mode), and the readable LCD display allows you to monitor the entire process.

This is a reliable solution for any driver who focuses on technology, safety and convenience.

Functions and features

• Universal use – charging lead-acid batteries 12V (2 – 100Ah)

• Microprocessor control – automatic adjustment of charging mode and disconnection after full charge

• Summer and winter mode – automatic voltage correction depending on the ambient temperature

• Special Start-Stop mode – safe charging of modern EFB and AGM batteries

• Repair function – regenerates and activates deeply discharged batteries

• Multi-stage protection – protection against short circuit, overheating, reverse polarity, overload and overvoltage

• Clear LCD display – shows voltage, charging current and battery level

• Backup mode – keeps the battery fully ready after charging

Construction

• Compact, fireproof ABS housing

• One control button (MODE) – selection of vehicle mode and repair function

• Large, easy-to-read LCD display with backlight

• Crocodile clamps with full insulation – safe and durable connection

• Aluminum heat sink and silent cooling fan – effective heat dissipation

• Thick copper wire – a guarantee of stable conductivity and performance

Advantages of the product

• Full automation – the device recognizes the battery itself and controls the charging process

• High efficiency and safety – microprocessor system and multi-stage protection

• Recovery function – restores efficiency even to deeply discharged batteries

• Ambient temperature mode – better charging efficiency in winter and summer

• Simple one-button operation – convenience and intuitiveness for every user

Technical data

• Model: RJ-C 120501A
• Rectifier type: Microprocessor, automatic
• Input voltage: AC 110–220V / 50 – 60Hz
• Output voltage: DC 13.8–15.5V
• Output current: to 6A
• Battery capacity range: 2 – 100Ah
• Type of batteries: Lead-acid, AGM, EFB, GEL, VRLA
• Working modes: Car / Motorcycle / Start-Stop / Repair
• Working temperature: -10°C to +40°C
• Dimensions: 150 × 85 × 62 mm
• Weight: 0,4 kg
• Input cable length: 90 cm
• Output cable length: 65 cm
• Cooling: Fan + aluminum heat sink
• Housing: ABS plastic, fire retardant
• Security: Reverse polarity, short circuit, overheating, overvoltage, overload
• Energy efficiency: >85%

Very wide application

• Passenger cars and trucks

• Motorcycles, scooters and quads

• Boats and yachts

• Agricultural and construction machinery

• Start-Stop batteries (EFB/AGM)

Connection instructions

1. Connect the red crocodile to the electrode +

2. Connect the black crocodile to the electrode -

3. After properly connecting the rectifier - the battery parameters will appear on the display.

4. In case of incorrect connection, the following inscription will appear on the display: reverse conection - then you need to change the crocodile connections

5. Insert plug into 220 V power supply

6. Select the MODE type of rectifier operation

7. When charging is finished on the display, the battery is full 100%.

8. For better charging, you can leave the battery connected to the charger for another hour

9. We disconnect the device in reverse order: first we pull the plug from the contact, then we disconnect the black crocodile, and finally the red one.

Why is it worth having this rectifier?

The RJ-C 120501A rectifier is a combination of power, precision and intelligent charging. Thanks to the advanced microprocessor, it adjusts the parameters to the type of battery itself, protecting it from damage. The repair function and Start-Stop mode make it an indispensable tool in both the garage and workshop.

Invest in technology that protects your battery and saves you money.

Buy the RJ-C 120501A rectifier and enjoy trouble-free start-up all year round!

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With a VAT invoice
Parametry	Model	Prostownik Mikroprocesorowy 12V 6A
Parametry	Brand	Foxsur
Parametry	Maximum amperage	6 A
Parametry	Product weight with unit packaging	0.15 kg
Parametry	EAN (GTIN)	5904310260015
Parametry	Batteries included	no
Parametry	Packaging status	original
