Automobilinė multimedija Audi A4 2002–2008, 9", Android 15, 4+64 GB, CarPlay, WiFi, su kamera

Trumpai apie prekę

Prekė: Automobilinė multimedija Audi A4 2002–2008, 9", Android 15, 4+64 GB, CarPlay, WiFi, su kamera. Kategorija: Radijo grotuvai.

• Gamintojas: no brand
• Modelis: RAF1939

TECHNICAL PARAMETERS

• Operating system: Android 15
• Processor: Quad-Core ARM Cortex-A55
• CPU clock speed: up to 1,6 GHz
• Graphic layout: Mali-G52 2EE
• RAM: 4 GB
• Internal memory: 64 GB
• Display: 9" LCD with capacitive touch panel
• Screen resolution: 1280 × 800
• Wi-Fi: Wi-Fi 6 Dual Band 2,4 GHz + 5,8 GHz
• Wi-Fi standard: 802.11 a/b/g/n/ac/ax
• Bluetooth: hands-free calls, music playback and phone book synchronization
• Apple CarPlay: wired and wireless
• Android Auto: wired and wireless
• Mirror Link: wired and wireless connection
• Navigation: GPS / BDS / GLONASS
• Radio: AM/FM with RDS
• Scope FM: 65 – 108 MHz
• DSP: digital sound processor
• Sound Corrector: 15-Band EQ
• Split Screen: supported
• Audio formats: MP3, FLAC, APE, WMA, WAV, AAC, M4A, AMR, Opus, MID, OGG
• Video formats: AVI, ASF, MP4, MOV, MPG, MPEG-1/2/4, VOB, MKV, FLV, TS, WMV, RMVB, 3GP
• Video decoding: H.264/AVC and H.265/HEVC
• Video support: high-resolution content up to 4K
• System languages: English, Polish, Slovak, Czech, Hungarian, German, French, Italian, Spanish, Portuguese, Russian, Turkish and others
• Control from the steering wheel: operated by CANBUS
• Reversing camera input: CVBS and AHD up to 1080P
• Support for 360° cameras: yes, when connected to a compatible kit
• USB: 2 USB connectors
• Audio outputs: RCA and SUB
• Audio inputs: AUX and external microphone
• Working voltage: 8 – 16,5 V
• Working temperature: from -30°C to +75°C
• Power consumption after ACC off: to 8 mA
• Deep sleep current consumption: to 3 mA

RADIO NAVIGATION ANDROID 15 TO AUDI A4

COMPATIBILITY

• Audi A4: 2002 – 2008

Before buying, compare the appearance of the center console, factory radio and connectors in the car with the photos on offer.

CARPLAY, ANDROID AUTO, BLUETOOTH AND WI-FI 6

• The radio supports Apple CarPlay and Android Auto wired and wireless. Once your phone is connected, you can use maps, music, calls, messages, and compatible apps right on your device screen.
• The Mirror Link function allows you to display an image from your smartphone. Bluetooth supports hands-free calling, music playback, and phone book downloads.
• Dual-band Wi-Fi 6 2,4 GHz + 5,8 GHz provides a fast and stable connection to your phone's hotspot or other wireless network.

9" 1280 × 800 SCREEN AND EFFICIENT SYSTEM

• The capacitive 9" touch screen with a resolution of 1280 × 800 provides a clear image, clear maps and convenient operation of applications and media.
• Android 15, ARM Cortex-A55 quad-core processor, Mali-G52 2EE graphics chip and 4 GB RAM and 64 GB internal memory allow you to enjoy navigation, music and other applications smoothly.
• The Split Screen function allows you to view two applications at the same time, such as a map and a music player.

ONLINE AND OFFLINE GPS NAVIGATION

• The built-in navigation module supports GPS, BDS and GLONASS systems.
• When connected to the Internet, the radio works with popular online navigation applications. After downloading the maps to the device memory, navigation can also work without access to the Internet.

DSP, 15-BAND EQ, RADIO RDS AND CANBUS

The built-in DSP sound processor and 15-band EQ allow you to adjust the sound to your preferences.

Radio supports:

• AM/FM tuner with RDS
• tone adjustment and 15-band equalizer
• RCA and SUB outputs
• external amplifier and subwoofer
• AUX input
• external microphone
• Steering wheel button control by CANBUS

AHD REVERSING CAMERA INCLUDED

• The set includes a AHD reversing camera. The radio supports CVBS and AHD signals up to 1080P, automatic image display when reverse gear is turned on, auxiliary lines and mirroring function.
• The device can also work with compatible 360° camera systems.

MULTIMEDIA AND CONNECTORS

The radio supports a wide range of popular audio and video formats:

• Audio: MP3, FLAC, APE, WMA, WAV, AAC, M4A, AMR, Opus, MID and OGG
• Video: AVI, ASF, MP4, MOV, MPG, MPEG-1/2/4, VOB, MKV, FLV, TS, WMV, RMVB and 3GP
• Video decoding: H.264/AVC and H.265/HEVC
• Video support: high-resolution content up to 4K
• External memory: USB devices

Two USB connectors allow you to connect your portable memory, phone or compatible accessories. The radio is also equipped with an AUX connector, RCA audio outputs, SUB output for the subwoofer, CVBS/AHD reversing camera input and external microphone input.

CONTENTS OF THE SET

• Android 15 radio with 9" screen
• AHD reversing camera
• CANBUS module
• main power harness
• 2 radio antenna adapters
• GPS antenna
• RCA cable
• reversing camera input cable
• 4-pin USB cable
• 6-pin USB cable
• external microphone
• dismantling tool
• installation instructions

IMPORTANT INFORMATION BEFORE PURCHASE

• The product is designed for Audi A4 from 2002 to 2008 with console and factory radio compatible with photos marked as compatible. Does not match the version shown in the third example in the matching table.
• In High-Trim versions, use the appropriate antenna adapter from the kit and connect its power cord to the ACC. The original car microphone is not supported – use the external microphone from the kit. The CANBUS module is pre-connected to the beam and should not be disconnected.
