Auto pastiprinātājs DD Audio ATC-250, 1 kanāls, Class D

Trumpai apie prekę

Prekė: Automobilinis stiprintuvas DD Audio ATC-250, 1 kanalo, Class D. Kategorija: Stiprintuvai.

• Gamintojas: DD AUDIO
• Modelis: ATC-250

⭐ DD AUDIO ATC-250 – COMPACT CLASS D MONOBLOCK

DD Audio ATC-250 is an extremely compact 1-channel car amplifier class D, designed primarily to power the subwoofer in the Car Audio system.

The amplifier offers 100 W RMS at 4 Ω, 225 W RMS at 2 Ω and 325 W RMS at 1 Ω, while maintaining very small dimensions of only 74,5 × 95,5 × 52,2 mm.

Stable operation at 1 Ω allows you to use the ATC-250 with different subwoofer configurations, and the high efficiency of the D class reduces the need for space and energy compared to larger designs.

The set also includes a wired remote control, allowing you to conveniently adjust the bass level from the driver's seat.

⭐ TECHNICAL SPECIFICATION DD AUDIO ATC-250

✅ Producer: DD Audio

✅ Model: ATC-250

✅ Type: monoblock / 1-channel amplifier

✅ Working class: D

✅ Number of channels: 1

✅ RMS power at 4 Ω: 1 × 100 W

✅ RMS power at 2 Ω: 1 × 225 W

✅ RMS power at 1 Ω: 1 × 325 W

✅ Dynamic / peak power: 500 W

✅ Minimum Impedance: 1 Ω

✅ Supply Voltage: 8 – 16 V

✅ Test voltage: 14,4 V

✅ Maximum current consumption: 40 A

✅ RCA input sensitivity: 0,2–8 V

✅ Signal-to-noise ratio S/N: 100 dB

✅ Damping factor: 150

✅ THD: 1%

✅ SUB band: 30 – 80 Hz

✅ FR band: 80 Hz – 20 kHz

✅ HPF filter: 80 Hz

✅ LPF filter: 80 Hz

✅ Recommended power cord: 4 AWG

✅ Recommended speaker cable: 12 AWG

✅ Dimensions: 74,5 × 95,5 × 52,2 mm

✅ Remote control: yes

⭐ WHY CHOOSE DD AUDIO ATC-250?

DD Audio ATC-250 is a good solution for installations where a separate subwoofer amplifier is needed, but the amount of available space is very limited.

✔ 325 W RMS at 1 Ω – adequate power to power the compact subwoofer section.

✔ Stability at 1 Ω – greater possibilities of subwoofer and its coil configuration.

✔ Class D – high efficiency and small size of the amplifier.

✔ Extremely compact housing – only 74,5 × 95,5 × 52,2 mm, which gives very large possibilities of hidden assembly.

✔ LPF filter – the ability to adjust the range of the amplifier to the subwoofer.

✔ Pilot included – convenient bass level adjustment from the car cabin.

✔ S/N 100 dB – very good signal-to-noise ratio.

✔ Maximum current consumption 40 A – a compact amplifier that does not require such an extensive power supply as large monoblocks.

📦 CONTENTS OF THE SET

✅ 1 × amplifier DD Audio ATC-250

✅ 1 × Wired remote control

✅ Accessories provided by the manufacturer

✅ Original manufacturer packaging
