Išmaniųjų namų valdymo blokas Aeotec AutoPilot Z-Wave 700 Gen7 API serveris

Trumpai apie prekę

Prekė: Išmaniųjų namų valdymo blokas Aeotec AutoPilot Z-Wave 700 Gen7 API serveris. Kategorija: Centriniai blokai.

• Gamintojas: no brand
• Modelis: AEOEZWA029

Z-Wave Plus V2 | MQTT | REST API | Local Logic

Are you looking for a smart home heart that gives you complete control? Aeotec AutoPilot is an advanced hardware and software platform, created for integrators, developers and enthusiasts for whom ready-made, closed systems are not enough.

The device is based on the efficient Orange Pi Zero H3 architecture and is equipped with a native Z-Wave 700 (Gen7) series radio module. This is no ordinary consumer gateway – it is a powerful tool that combines the stability of dedicated hardware with the flexibility of open source software.

📡 Z-Wave 700 Series (Gen7) Technology

AutoPilot is equipped with the latest Z-PI7 chipset. Compared to older goals (500 series), it offers:

• Greater range: Up to 150m in open area (better wall penetration).
• Speed: Lightning-fast device response and lower Mesh latency.
• Security: Full support for Security S2.
• SmartStart: Easily add devices by scanning the QR code.

🏠 Local Intelligence (Privacy & Reliability)

In the world of AutoPilot, the cloud is an option, not a necessity. All automations, scenes and processes are processed locally on the device.

• Brak Internet? Your house is still working. The lights respond to motion sensors without delay.
• Privacy: Your data is not sent to external servers if you do not want it to be sent.

🔗 Integrator Paradise (API & MQTT)

AutoPilot is the perfect "bridge" connecting the world of Z-Wave with other systems.

• REST API: Full documentation allows you to control the gateway from external applications.
• MQTT: Native MQTT support enables easy integration with Home Assistant, Node-RED or BMS systems in office buildings.

💻 Convenient "AutoPilot UI" Interface

Configuration is done through a responsive panel in the web browser.

• Logic Editor: Create advanced "If... It's..." scenarios using logical blocks.
• Dashboard: Monitor sensor status, power consumption and camera in one place.

• Smart Home: As the main home controller (lighting, heating, blinds).
• Hotels and Offices: With the ability to clone configurations and remote management, AutoPilot is great for repeatable installations (e.g. control of hotel rooms).
• Developers: As a base for building your own Smart Home system under your own brand.

• Model: Aeotec AutoPilot (OEM/Development Version)
• Processor: Orange Pi Zero H3 (QuadCore ARM Cortex A7)
• RAM: 512 MB DDR3
• Z-Wave Radio: Aeotec Z-PI7 (Series 700 / Gen7)
• Network communication: Ethernet 100M + Wi-Fi
• Power Supply: USB (5V)
• System: AutoPilot OS (Linux-based)
• Z-Wave standards: Z-Wave Plus V2, SmartStart, S2 Security

1. Aeotec AutoPilot gateway
2. USB AC adapter
3. Power cord
4. Ethernet cable (LAN)
