Išmanusis šviesos dimmeris SONOFF MINI-DIM-E, WiFi, LED, 200VA, 400W, su tvarkaraščio funkcija

Trumpai apie prekę

Prekė: Išmanusis šviesos dimmeris SONOFF MINI-DIM-E, WiFi, LED, 200VA, 400W, su tvarkaraščio funkcija. Kategorija: Automatizavimo moduliai.

• Gamintojas: Sonoff
• Modelis: MINI-DIM-E

SONOFF MINI-DIM-E smart switch with Matter over WiFi support. It allows you to smoothly adjust the brightness of lighting, create scenes, and monitor power consumption. It supports schedules, smart scenes, and voice control, so you can easily adjust the lighting to suit your time of day and your habits. Automatic calibration makes it easier to adjust to the connected load, and built-in protection – against overheating and surges – increases work safety.

• Manufacturer: Sonoff
• Product name: Orb-DIM
• Model: MINI-DIM-E
• Housing material: PC
• Wi-Fi: Wi-Fi IEEE 802.11b/g/n 2,4 GHz
• Working temperature: -10°C~40°C
• Rated voltage: 220 – 240 V ~ 50 Hz
• Rated power: max. 400 IN
• Dimensions: 86 x 86 mm

• smart switch
• screws x4
• instruction manual

Orb-DIM allows you to adjust brightness in the full range from 0 to 100%. You can precisely adjust the light to the situation – from a gentle night light to full power while working or reading. The preset function allows you to quickly set the selected level, which speeds up daily use. The use of trailing-edge dimming increases compatibility with modern light sources and reduces the flickering effect.

The switch works with different types of light sources. It supports dimmable LED bulbs up to 200 VA, traditional and halogen bulbs up to 400 W and dimmable electronic transformers up to 200 W. This gives you the freedom to choose lamps without having to replace the entire installation. Note: The device is not designed for fluorescent lamps, LED strips or induction loads such as fans.

MINI-DIM-E works in the Matter standard, which allows you to integrate it with popular systems such as Apple Home, Google Home, Amazon Alexa, SmartThings and Home Assistant. This allows you to control the light from a variety of apps and voice assistants in one home. A compatible Matter hub is required to operate in the Matter ecosystem. Once connected, the device can be part of larger automations and scenes throughout the system.

Orb-DIM is designed to work seamlessly with Apple Home. Brightness control, scene creation, and voice control via Siri are done right in the app, making it easy to set up and use every day.

The built-in power measurement function allows you to check the current power consumption of the connected lighting. This allows you to consciously manage brightness and control energy costs, especially at heavily used light points.

The switch allows you to set schedules for turning the light on and off, create scenes that match the time of day, and use voice control. You can program the action so that in the evening in the living room a gentle light burns, stronger in the morning or automatic dimming at a certain time. Support for the eWeLink app allows for quick pairing, and in the case of Matter, you just need to scan the configuration code to add the device to the system.

The device is equipped with overheating protection and surge protection. The housing is made of flame retardant material, and the whole meets CE and RoHS standards. The relay is designed for long and stable operation, which translates into greater reliability in everyday use. In addition, the MINI-DIM-E fits type 86 cans and European 60 mm round cans. Thanks to this, it will work both in new installations and in the modernization of existing equipment.

Specifications
