Multimedijos sistema Ford Focus 2004–2010, 9", Android 15, 4+64 GB, CarPlay, WiFi

Trumpai apie prekę

Prekė: Multimedijos sistema Ford Focus 2004–2010, 9", Android 15, 4+64 GB, CarPlay, WiFi. Kategorija: Radijo grotuvai.

• Gamintojas: no brand
• Modelis: RAF2411

TECHNICAL PARAMETERS

• Operating system: Android 15
• Processor: Quad-Core ARM Cortex-A55
• CPU clock speed: up to 1,6 GHz
• Graphic layout: Mali-G52 2EE
• RAM: 4 GB
• Internal memory: 64 GB
• Display: 9" LCD with capacitive touch panel
• Screen resolution: 1280 × 800
• Wi-Fi: Wi-Fi 6 Dual Band 2,4 GHz + 5,8 GHz
• Wi-Fi standard: 802.11 a/b/g/n/ac/ax
• Bluetooth: hands-free calls, music playback and phone book synchronization
• Apple CarPlay: wired and wireless
• Android Auto: wired and wireless
• Mirror Link: wired and wireless connection
• Navigation: GPS / BDS / GLONASS
• Radio: AM/FM with RDS
• Scope FM: 65 – 108 MHz
• DSP: digital sound processor
• Sound Corrector: 15-Band EQ
• Split Screen: supported
• Audio formats: MP3, FLAC, APE, WMA, WAV, AAC, M4A, AMR, Opus, MID, OGG
• Video formats: AVI, ASF, MP4, MOV, MPG, MPEG-1/2/4, VOB, MKV, FLV, TS, WMV, RMVB, 3GP
• Video decoding: H.264/AVC and H.265/HEVC
• Video support: high-resolution content up to 4K
• System languages: English, Polish, Slovak, Czech, Hungarian, German, French, Italian, Spanish, Portuguese, Russian, Turkish and others
• Control from the steering wheel: operated by CANBUS
• Reversing camera input: CVBS and AHD up to 1080P
• Support for 360° cameras: yes, when connected to a compatible kit
• USB: 2 USB connectors
• Audio outputs: RCA and SUB
• Audio inputs: AUX and external microphone
• Working voltage: 8 – 16,5 V
• Working temperature: from -30°C to +75°C
• Power consumption after ACC off: to 8 mA
• Deep sleep current consumption: to 3 mA

RADIO NAVIGATION ANDROID 15 TO FORD FOCUS

COMPATIBILITY

• Ford Focus: 2004–2010
• Versions with manual and automatic air conditioning

Before buying, compare the appearance of the center console, factory radio and connectors in the car with the photos on offer.

CARPLAY, ANDROID AUTO, BLUETOOTH AND WI-FI 6

• The radio supports Apple CarPlay and Android Auto wired and wireless. Once your phone is connected, you can use maps, music, calls, messages, and supported apps right on your device screen.
• The Mirror Link function allows you to display an image from your smartphone. Bluetooth allows you to make phone calls via hands-free and wirelessly play music.
• Dual-band Wi-Fi 6 2,4 GHz + 5,8 GHz provides a fast and stable connection to your phone's hotspot or other wireless network.

9" 1280 × 800 SCREEN AND EFFICIENT SYSTEM

• The large capacitive 9" touch screen with a resolution of 1280 × 800 provides clear images, clear navigation and convenient application operation.
• Android 15, quad-core processor and 4 GB RAM and 64 GB internal memory allow you to install applications, save maps, music, videos and other media files.
• The Split Screen function allows you to use two applications at the same time, for example navigation and music player. There are also various home screen themes so you can customize the look of the menu to your preference.

ONLINE AND OFFLINE GPS NAVIGATION

• The built-in module supports GPS, BDS and GLONASS positioning systems. The radio works with popular online navigation apps, and once you download the appropriate maps, it can also work without internet access.
• The large screen makes it easy to read the route, navigation messages and information about subsequent maneuvers.

DSP, RADIO RDS AND STEERING WHEEL CONTROL

The built-in DSP sound processor and 15-band EQ allow you to adjust the sound settings to your preferences.

Radio supports:

• AM/FM tuner with RDS
• tone adjustment and 15-band equalizer
• sound balance setting
• RCA and SUB outputs
• external amplifier and subwoofer
• compatible buttons on the steering wheel
• external microphone for conducting conversations

Steering wheel control allows you to adjust the volume, change tracks and support other assigned functions without taking your hands off the steering wheel.

AHD REVERSING CAMERA INCLUDED

• The set includes a AHD reversing camera. The radio supports CVBS and AHD signals up to 1080P, automatic image display when reverse gear is turned on, auxiliary lines and mirroring function.
• The camera provides real-time image preview and facilitates safe reversing and parking. The device also supports compatible 360° camera systems.

MULTIMEDIA AND CONNECTORS

The radio supports a wide range of popular audio and video formats:

• Audio: MP3, FLAC, APE, WMA, WAV, AAC, M4A, AMR, Opus, MID and OGG
• Video: AVI, ASF, MP4, MOV, MPG, MPEG-1/2/4, VOB, MKV, FLV, TS, WMV, RMVB and 3GP
• Video decoding: H.264/AVC and H.265/HEVC
• Video support: high-resolution content up to 4K
• External memory: USB devices

Two USB connectors allow you to connect your portable memory, phone or compatible accessories. The radio is also equipped with an AUX connector, RCA audio outputs, SUB output for the subwoofer, CVBS/AHD reversing camera input and external microphone input.

CONTENTS OF THE SET

• Android 15 radio with 9" screen
• Matching panel for Ford Focus
• AHD reversing camera
• main power harness
• CANBUS module or beam
• GPS antenna
• radio antenna adapter
• RCA cable
• reversing camera cable
• USB cable
• external microphone
• dismantling tool
• installation instructions

IMPORTANT INFORMATION BEFORE PURCHASE

• The radio fits the Ford Focus 2004 – 2010 with both manual and automatic air conditioning. Before buying, you should compare the console and factory connector with the photos in the offer.
• After installation, steering wheel control may require selecting the Universal Model mode and manually assigning buttons in the SW Learning application. The factory microphone should be replaced with the external microphone included in the kit.
