Oro filtravimo kasetė Frapol Onyx Sky 1000 M5 ePM10 55%

Trumpai apie prekę

Prekė: Oro filtravimo kasetė Frapol Onyx Sky 1000 M5 ePM10 55%. Kategorija: Dalys.

• Gamintojas: Murano Feniks
• Modelis: 18188344AI

Murano Feniks

• Air filter type: Harmonic minipleat
• Scope of filtration efficiency: Anti-pollen
• Filter material used: Glass microfibres
• Filter class EN779:2012: EU5 / M5
• Filter standard DIN EN ISO 16890: ePM10 55%
• Filter frame type: Waterproof carton coated with foil
• List of air filter sizes: 180 * 400 * 25 mm, 400 * 180 * 25 mm
• Brand Model Ventilation Unit: Frapol Onyx Pride 400, Frapol Onyx Sky 500, Frapol Onyx Premium 500, Frapol Onyx Compact 500, Frapol Onyx Compact 750, Frapol Onyx Dream 400, Frapol Onyx Sky 1000

Finely pleated filter

M5 ePM10 55% 180 x 400 x 25 mm

Manufacturer name Murano Feniks: MF/MPT/WRD M5 EPM10 55% 180x400x25 mm

Pollen filter with cardboard frame for indirect filtration in mechanical ventilation, recuperation and air conditioning units. The construction of the filter is a cartridge made of finely pleated glass microfibers in minipleat technology separated by hot melt separators allowing the formation of plits with a rigid structure. The filter package is then tightly pasted into the cardboard housing. The fine harmonica allows for maximum use of the frame volume by obtaining the largest filter surface, ensuring maximum long filter operation. Filter paper made of glass microfibers with increasing density at the exhaust side of the air from the filter provides very low resistance throughout the filter period with impurities. Anti-pollen cartridge filter pleated finely into filter packages in filtration class M5 with ePM10 55% efficiency in the dimension 180x400x25 mm allows to capture 55% of intermediate particles from the air, i.e. spores, cement dust and other impurities less than 10 μm (micrometers). We count it as medium filters. Thus, this filter allows for average air filtration in mechanical ventilation control panel systems with heat recovery called recuperation. Our filters are made of materials that meet high energy classes to ensure the lowest possible consumption of electricity by your recuperator.

Technical data:

Cassette filter minipleat M5/EU5 ePM10 55%

Dimensions:

• Width: 180 mm
• Length: 400 mm
• Frame depth: 25 mm

Parameters:

• Filter material: glass microfiber cartridge

• Frame type: foil-coated waterproof carton

• Filtration class according to EN 779:2012: M5

• Filtration class according to ISO 16890: ePM10 55%

• Maximum operating temperature: < 80 °C

Filter material:

• Glass microfiber cartridge. Molded into filter packages in minipleat technology with hot melt separators.

Construction:

• Completely sealed design.

• Cartridge pasted in a cardboard frame.

• Increased filter surface area for longer filter operation.

Application:

• Filter used in places where high air purity is required, e.g. pharmaceutical, electronics, medical, food industry.

Properties:

• Glass microfiber cartridge

• Anti-pollen

• Extra-large filter surface

• High efficiency

• Low operating costs

• Long lifespan

• Resistant to high temperatures

• Standard and special dimensions

• Filters are made in accordance with the requirements of the Quality Management System ISO 9001 ensures that the product constantly maintains the highest quality.

The air supplied by ventilation, air conditioning and recuperation systems is as clean as the filters that clean them and therefore the quality of filters and their reliability and durability has a huge impact on the operation of the entire ventilation system and the air quality provided by it.

Intermediate filter with cardboard frame for mechanical ventilation unit with dimension 180x400x25 mm in filtration class m5 eu5 with efficiency ePM10 55%. Providing pollen filtration for home, office and business air. Finely pleated filter in minipleat technology to ensure maximum large filter surface with cardboard frame and glass tissue insert with high efficiency in capturing impurities. Pollen filter to meet the level of indirect air filtration in mechanical ventilation, recuperator.

Murano Feniks 18188344

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	Murano Feniks
Parametry	Kind	filter
Parametry	Manufacturer code	18188344AI
Parametry	Packaging status	original
Parametry	Batteries included	no
