Oro kompresorius 10 bar, 550 l/min, alyvos tepimo, modelis 2070++

Trumpai apie prekę

Prekė: Oro kompresorius 10 bar, 550 l/min, alyvos tepimo, modelis 2070++. Kategorija: Kompresoriai.

• Gamintojas: Kowal Polska
• Modelis: KowaL 2070++ 10 BAR
• Galia: 2.2 kW

• Compressor + connection tube 30 cm + check valve

• New, improved design!
• 2 vents were used in the construction of this model
• side exhaust air cooler
• enlarged valve seats for faster airflow
• Raised head heat sink
• air outlet pipe with aluminium heat sink, ribbed
• increased compression ratio to 10 BAR
• free connection tube + check valve

• max suction capacity: 550 L-min
• max working capacity: 336 L-min
• required min engine power: 2,2 kw
• Suggested cylinder capacity: 50 to 250 L
• required compressor rated speed: 800-1150 r/min
• max. working pressure: 10 bar
• Weight: about 15 kg
• Piston diameter: 2 x 70 mm
• pulley diameter: 26 cm
• Drive: 1 x 13 mm V-belt
• spacing of fixing screws: 13,5 x 14 cm
• direction of rotation: left (looking from the side of the wheel)
• oil used: compressor LD-100
• 1 replacement after 5 hours, then every 50 hours
• lubrication: splash
• Cylinders: cast iron
• correct oil level: covered 3/4 slide
• Check the oil level before each start. If necessary, supplement its condition.

• 2 piston compressor (2 x 70 mm)
• AIR FILTER
• 2 mounting screws
• 2 ventilators
• compressor and tube outlet heat sink fitting
• 1/2'' check valve
• connection tube with heat sink and 2 screws
• before shipment, each compressor flooded with the company LD-100 oil

• BRAND KowaL - 10 YEARS OF EXPERIENCE IN THE PNEUMATICS INDUSTRY, THOUSANDS OF SATISFIED CUSTOMERS
• CERTIFIED PRODUCT WITH UNINFLATED PARAMETERS
• CERTAINTY OF PROFESSIONAL ADVICE ON PURCHASE AND SERVICE
• WE HAVE OUR OWN SERVICE (AVAILABILITY OF ALL PARTS TO OUR PRODUCTS DURING WARRANTY AND POST-WARRANTY TIME)
• ONLY WITH US THIS CLASS PRODUCT AT SUCH A LOW PRICE WHICH WILL BE USED IN ALL CONDITIONS IN WHICH IT WILL WORK!
