Oro užuolaida AERIS AC200E1P, 2 m, 230 V, balta

Trumpai apie prekę

Prekė: Oro užuolaida AERIS AC200E1P, 2 m, 230 V, balta. Kategorija: Oro užuolaidos.

• Gamintojas: Reventon
• Modelis: AERIS AC200E1P
• Galia: 350 W

The AC200E1P is a powerful device with a width of 2 meters, designed to protect wide door openings in commercial, office and hotel facilities. Thanks to the use of efficient electric heaters, the curtain creates an effective thermal barrier that retains heat inside the building in winter and prevents heat, dust and insects from entering in summer.

⚙ Instant Heating and Full Control

The device is equipped with an advanced heating system, which is characterized by low thermal inertia – this means that the air is heated almost immediately after starting. It is ideal for high-traffic areas where doors are often opened.

💨 Maximum Range Over the Wide

Thanks to the two-meter design and reinforced transverse fans, the curtain generates a uniform, strong air stream with a range of up to 2,5 meters. This guarantees full coverage of even wide double-leaf entrances, eliminating "dead zones" through which air could escape.

🛡 Premium Design and Design

The minimalist white powder coated steel housing (RAL 9016) makes the device look modern and professional. The robust construction is resistant to thermal deformation, and high-quality components ensure quiet and trouble-free operation for many years.

🔌 230V power supply – Universal Installation

Despite its size and high heating power, the curtain operates at a voltage of 230V, which allows it to be installed in facilities that do not have a power connection (400V). The integrated mounting system allows you to quickly hang the device above the door.

WORKING PARAMETERS:

• Width of the device: 2000 mm (2 meters)
• Heater type: Electric
• Maximum flux range: 2,5 m
• Maximum airflow: 2500 m³/h
• Power supply: 230V / 50Hz

📦 SET COMPOSITION – WHAT YOU WILL GET:

• ✅ Electric air curtain – AERIS AC200E1P (200 cm)
• ✅ Complete mounting bracket system
• ✅ Instructions for use and assembly – in Polish
• ✅ Guarantee Card

ASSEMBLY:

• Mounting type: Levels (wall or underfloor)
• Recommended mounting height: Up to 2,5 m above the floor
• Advantage: Possibility of mounting two devices side by side at extremely wide entrances.

EXTERNAL DIMENSIONS:

• A (Total width): 2000 mm
• G (Total depth): 215 mm
• H (Total height): 180 mm

ASSEMBLY DIMENSIONS (Sheet):

• B (Total spacing of extreme holes): 1520 mm
• C (First section spacing): 520 mm
• D (Second section spacing): 520 mm
• E (Height between holes): 130 mm
• F: 143 mm
