Rokasbetona urbis WABROTECH WT112, 1500W, 112 mm

Trumpai apie prekę

Prekė: Rankinis betono gręžimo įrenginys WABROTECH WT112, 1500W, 112 mm. Kategorija: Grunto grąžtai.

• Gamintojas: WABROTECH
• Modelis: 01-1K-003WT112
• Svoris: 7 kg

• External thread: 1 ¼” UNC
• Internal thread: ½”
• Engine power: 1500 Watt
• Power supply: 230 V / 50 Hz
• Rotation speed:
• 1. Run 0 – 880 rpm.
• 2. Run 0 – 1990 rpm.
• 3. Run 0 – 3960 rpm.
• Soft-start (slow start): YES
• Drilled hole diameter range: 8 mm – 112 mm
• (for reinforced concrete and hard stone up to 82mm)
• Maximum drill length: 450 mm
• Max. dimensions: 270 x 170 x 510 mm
• Weight: 7 kg

CE declaration of conformity - our products meet the requirements of European Union directives

Professional drilling rig WT112 by WABROTECH is a practical model recommended for drilling in hard construction materials. Robust construction made mostly of steel and aluminum castings and versatility makes the device suitable for applications throughout the construction industry, and materials such as natural stone, asphalt, reinforced concrete or brick are not a challenge when drilling.

The presented model can be mounted on a tripod with a 60 mm clamp.

The drilling rig has a powerful 1500 W motor.

WT112 has a gearbox with a 3-speed transmission, which will allow you to better choose the drilling speed depending on the diameter of the hole and the material. Choosing the right speed of rotation facilitates drilling with different drill diameters, improves the comfort of work. Properly selected rotation speed also reduces the wear of the drill.

The mechanical clutch in the device protects the engine and transmission from the adverse effects of overloads. In addition, an overcurrent circuit breaker is also used, which controls the shutdown of the device with excessive voltage surge.

Integrated connection to the water supply network allows wet drilling, which significantly increases the service life of most drills

Our core drill uses a mechanical clutch that protects the transmission and engine from damage. However, if the crown drill is jammed in the workpiece material during manual drilling, the machine may rotate rapidly, which may pose a potential hazard to the operator. Therefore, where possible, we recommend using the stand for drilling rigs, whose task is to increase the stability of the device, minimizing the risk of uncontrolled rotation and increasing the overall level of work safety.

High-quality machine bearings guarantee stable operation, which translates into increased drill life.

The spindle with ½” and 1 ¼” threads makes our drilling rig support virtually all drills and accessories available on the market.

The device has a protective PRCD residual current circuit breaker – crucial when drilling wet holes.

Video from our WT112 drilling rig on a WT45S inclined tripod:

• https://www.youtube.com/watch?v=lJG-YmOyyrQ

Included:

• 1 x Drilling Rig WT112
• 1 x Cooling Water Hose
• 1 x Flat Wrench 30 / 32
• 1 x Allen Wrench
• 1 x Side Handle
• 1 x Brush Set
• 1 x Carrying case (free)
• 1 x Manual
