Rekuperatorius Prana 200C Premium

Trumpai apie prekę

Prekė: Rekuperatorius Prana 200C Premium. Kategorija: Rekuperacinės vėdinimo sistemos.

• Gamintojas: Prana
• Modelis: PRANA ORIGAMI 200C Premium +

PRANA 200C PREMIUM+ recuperator

PRANA 200C PREMIUM+ recuperator

✅from the home series is a supply and exhaust countercurrent ventilation system (inflow and exhaust occur simultaneously without mixing air streams). The housing of the ventilation system is made of food grade ABC plastic. As an air recuperator, a high-performance copper heat exchanger was used. Equipped with atmospheric pressure sensor and air humidity. Determination of filter status. VOC air quality sensor, CO2 sensor, efficiency indicator.

✅ Temperature sensors (1- temperature of exhaust air after recuperation, 2- temperature of inlet air before recuperation, 3- temperature of inlet air after recuperation, 4- temperature of exhaust air before recuperation) Auto and auto PLUS mode of operation recommended for night work.

✅The recuperation module is equipped with replaceable filters, which, depending on the type used, do not allow pollutants in the air such as dust, pollen, insects and smog to enter the room.

Modern wall recuperators by PRANA® are innovative devices that are installed by our customers in:

✅apartments/houses

✅offices

✅universities/ schools/ kindergartens

✅ hospitals/clinics

✅gyms / warehouses

MAIN FEATURES:

• Air exchange m3/h: 6/25/35/48/90/140
• Air inlet and outlet simultaneously: Yes
• Efficiency: up to 93%
• Energy consumption: 3,2 – 91 W/h
• Mini-heating: Yes
• Working module length: from 500 mm
• Working diameter: 200 mm
• Diameter of mounting hole: from 210 mm
• Recommended installation location: up to 120 m2
• Housing insulation: Yes
• Management system: Remote control, mobile application Prana Remote Control
• Copper heat exchanger: Yes
• Certificate: European CE quality certificate
• Certificate: National Institute of Hygiene: B-BK-60212-0086/20
• Certified TUV fans: YES
• Thermomodernization relief: YES
• Clean air relief: YES

In short:

✅It has a function mini heating and winter mode to prevent icing of the condensate outflow.

✅ The ability to enable automatic mode.

✅Easy control with remote control (included with each model! )

✅Recuperators are synchronized with the mobile application for tablet and smartphone (Android, IOS), so you can control what happens to the air in your home regardless of where you are currently!

✅Diameter of mounting hole approx. 162 mm

✅ Length of working module approx. 45

What's the most important thing?

✅ Preserve the natural properties of air

✅ Ease of installation - Specialists install the recuperator on average within 2 hours, without damage and the need to renovate the entire apartment / facility.

✅High energy efficiency

✅Ergonomics and ease of use.

✅For existing facilities installation is simple and does not require a major overhaul.

✅The autonomy of the PRANA decentralised system eliminates the risk of failure of the central recuperation system (resulting in the elimination of recuperation of the entire facility) and, more importantly, reduces the risk of carbon dioxide poisoning and sedation (which may occur in the case of central recuperation systems).

✅No filters. Maintenance and consumables are not required.

✅Multifunctionality of the Prana hybrid recuperation system – easy adaptation to all types of premises and existing gravity channels.

✅ Compact size. Only ventilation grilles are noticeable, the recuperator remains masked in the wall.

Heat exchanger – the heart of the recuperator

✅Air streams run through the system of copper heat exchangers, located inside the operating module, but are divided between each other both inside the operating module, as well as at the "inlet - outlet" and are not mixed.

✅Thanks to the innovative design of the PRANA® recuperators, the efficiency factor reaches 94%. One of the significant achievements of the process of obtaining fresh air by the PRANA® recuperator is the lack of filters.

✅ Thanks to the abandonment of filters, the energy quality factor of air ranges from 95% to 97%. So high efficiency is achieved by passing air streams through a copper heat exchanger. This raw material is characterized by very good thermal conductivity, as well as antisepticity at a level similar to silver.

✅ The system removes air contaminated with microparticles of dust and smoke from the room, provides fresh and clean air from the outside.

✅ Additionally, in the ventilation system PRANA® "developed" warm air, which moves out of the room, heats cold air coming from the outside, and in the summer vice versa - cools down.

1. Copper heat exchanger.

2. The air supply and exhaust work simultaneously without mixing with each other.

3. 100-150mm distance from the ceiling.

4. Heated air from outside.

5. Removing warm air from the room.

6. Air removed from the room.

7. Air from the outside

8. Inclination of the installation at an angle of 2-3 degrees.

THE MAIN ADVANTAGES OF PRANA RECUPERATORS

PRANA is the author and manufacturer of a number of modern technologies in the field of energy savings. After more than 15 years of operation in the renewable energy and comfort of living industry, we have made an almost impossible, we have created an excellent and economically justified system of bioenergy comfort in rooms.

• COMPACT DIMENSIONS: housing diameter of the operating module - 150, 200, 250, 340 mm. Adjustable length - depending on the thickness of the walls.
• COPPER HEAT EXCHANGER: The basic feature of copper is excellent thermal conductivity, moreover, copper is an antiseptic (maximum similar to silver). An environment is created in the recuperator, ensuring air decontamination, viruses and bacteria lose their ability to develop and live.
• EFFICIENCY IS UP TO 96% : is achieved by passing exhaust and inlet air streams, heading in the opposite direction and not crossing each other, through the copper heat exchanger system.
• SPEED AND EASE OF INSTALLATION: In order to install the recuperator in a distributed system, a hole must be made in the outer wall of the building, in which an operating module is mounted using mounting foam or other sealant.
• ELECTRICITY CONSUMPTION FROM 4Wh.

Ventilation systems from our company are simple!

A wide range of models allows you to easily adjust the product to the individual needs of the customer and the size of the room. The manufacturer of recuperators used a combination of materials and technologies that restore the natural properties of air. As a result of these solutions, clean air was obtained, actively disinfected, while maintaining all the desired energy components (ion composition).

As a result of encapsulation (as a result of the use of the latest, airtight windows and doors), the indoor climate has deteriorated significantly. Not only the fungus, but also moisture very adversely affect the health of people, leading in extreme situations to a direct threat.

For existing facilities, the best solution is to use PRANA® distributed recuperation systems.

Comparison of Prana recuperators from the 200C series

Equipment Prana 200 Prana 200 Prana 200

Standard Stop Smog Premium+ recuperator model

Separate motor control ✅ ✅ ✅

Control via smartphone ✅ ✅ ✅

Time switch ✅ ✅ ✅

Filter contamination indicator ❌ ✅ ✅

Atmospheric pressure sensor ❌ ✅ ✅

Humidity sensor ❌ ✅ ✅

"AUTO" mode ❌ ✅ ✅

Temperature sensor 1 ❌ ✅ ✅

Temperature sensor 2 ❌ ✅ ✅

Temperature sensor 3 ❌ ❌ ✅

Temperature sensor 4 ❌ ❌ ✅

Performance indicator ❌ ❌ ✅

Air quality sensor, VOC ❌ ❌ ✅

CO2 sensor ❌ ❌ ✅

Specifications
