Relė WiFi, 2 kanalų, 5A, 230V, WI-R2S2-P FOX F&F

Trumpai apie prekę

Prekė: Relė WiFi, 2 kanalų, 5A, 230V, WI-R2S2-P FOX F&F. Kategorija: Išoriniai moduliai.

• Gamintojas: F&F
• Modelis: WI-R2S2-P

Channel Wi-Fi Relay 230V FOX DOUBLE SWITCH 2 WI-R2S2-P

Supply voltage 85÷265 V AC

Control input 85÷265 V AC

Control pulse current less than 1 mA

Maximum load current (AC-1) - rated current 2 x 5 A

Maximum load current (AC-1) - maximum current (instantaneous) 2 x 8 A

Humidity (non-condensing) less than 90%

Radio Frequency 2,4 GHz WI-FI Transmission

Radio power (IEEE 802.11n) below 13 dBm

Receiver sensitivity -98 dBm

Connection of screw terminals 2,5 mm?

Tightening torque 0,4 Nm

Standby power consumption: 1,2 W; operation (relay on): 2,2 W

Operating temperature 0÷45°C

Dimensions? 54 (48×43 mm), height: 20 mm

Installation in a flush-mounted box? 60

Degree of protection IP20

Note!!!

Shipping takes place up to two business days/48 hours. from the moment of placing the order. It is carried out depending on the time of purchase, usually on the same day, but for various reasons, independent of us, it can be sent the next day. If it is given for a longer time than the stated (2 days), i.e. that the product has sold out and we expect delivery, usually up to 3-7 days.

In urgent matters, please let us know.

Pictures of products in our offers are illustrative, do not suggest the parameters placed on them. The offer description includes the full specification.

Our business is conducted on many sales channels, which may result in a possible delay in updating inventory and executing orders.

Returns!!!

Returned products should be without signs of use or assembly, and with unprogrammed functions, i.e. in the condition it was sent (new). In any other case, the refund will be reduced in proportion to the reduced value of the product!

Electrical device, connection should be dealt with by a qualified person with electrical privileges. As a result of poor operation and installation, it can threaten electric shock or damage.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Kind	other
Parametry	Series	Fox WiFi
Parametry	Brand	F&F
Parametry	Power supply	mains
Parametry	Communication	WiFi
Parametry	Manufacturer code	WI-R2S2-P
Parametry	EAN (GTIN)	5902431674179
Parametry	Product weight with unit packaging	0.2 kg
Parametry	Certificates of conformity	CE
