USB vartai Sonoff Dongle Plus MG24 Zigbee, Thread, Zigbee2MQTT

Trumpai apie prekę

Prekė: USB vartai Sonoff Dongle Plus MG24 Zigbee, Thread, Zigbee2MQTT. Kategorija: Centriniai blokai.

• Gamintojas: Sonoff
• Modelis: Dongle-PMG24

⭐SONOFF Zigbee/Thread USB Dongle | Dongle Plus MG24

Advanced Zigbee/Thread adapter with EFR32MG24 chip. Supports Home Assistant, Zigbee2MQTT and other open-source platforms. Featuring an improved antenna and aluminum housing, it offers fast automation processing, wide range, and easy software flashing. Ideal for building an open and scalable smart home.

⭐The most important features

• Based on advanced EFR32MG24 chip with 1536KB Flash and 256KB RAM
• Support for Zigbee 3.0 and Thread protocols
• Wide compatibility with open-source platforms: Home Assistant, Zigbee2MQTT and others
• Amplified antenna with gain up to 4.5 dBi – greater signal range and stability
• Easy software flashing (coordinator/router) with dedicated web tools
• Includes USB extension cable (1m) to minimize electromagnetic interference
• Robust and compact aluminum alloy housing

⭐Main adapter for Open-Source platforms

Dongle Plus MG24 acts as a central adapter for popular open-source platforms, allowing you to connect and unified management of Zigbee devices from different brands. This makes it easier to build a diverse smart home ecosystem.

⭐Exceptional performance with EFR32MG24

The built-in high-performance EFR32MG24 chip provides faster automation processing and lightning-fast control of connected devices, while offering low standby power consumption.

⭐Flexibility with different software versions

With the official SONOFF Dongle Flasher tool, you can change software within a minute, converting dongles from a coordinator to a router (signal amplifier) and vice versa, depending on your network needs.

⭐ ZigBee protocol

What distinguishes ZigBee from classic WiFi is a sufficiently long working time of battery-powered devices (unattainable with the classic WiFi protocol) and signal transmission through accessories powered by 230V.

In addition, selected ZigBee devices (230V mains powered) become part of the Mesh network. This means that if a module is unable to connect directly to the ZigBee gateway, it communicates with it through another closest accessory of this system. The repater in the ZigBee ecosystem are devices powered by 230V, such as PSMART, Aqara T1, OXT Zigbee relay, Sonoff ZBMINI, TUYA, 230V sockets or bulbs.

Thanks to this, you can create an extensive network that can operate over much longer distances than classic WiFi.

ℹ Specification

• Model: Dongle-PMG24
• SoC system: EFR32MG24
• Power Supply: 5V DC / 500mA
• Power consumption at rest: 40 mW
• Signal range: up to 200m (in open space)
• Housing: Aluminum alloy
• Connection: USB-A

ℹ Contents of the set

1. SONOFF Dongle Plus MG24 ×1
2. Antenna ×1
3. USB extension cable (1m) ×1
4. User manual ×1
