Vandens aušintuvas CoolBox L Channel

Trumpai apie prekę

Prekė: Vandens aušintuvas CoolBox L Channel. Kategorija: Dalys.

• Gamintojas: Thesslagreen
• Modelis: 007A0004

Product Description:

CoolBox 200 L is a high-performance, 6-row water cooler designed for cooling air in ventilation ducts. It has been designed to cooperate with modern AirPack recuperators, ensuring effective reduction of the supply air temperature and high thermal comfort in buildings.

• Diameter of ventilation connections: Ø 200 mm
• Version: left execution

Standard equipment:

• Heat-insulated housing
• Possibility of cooperation with glycol ground heat exchanger (GGWC)
• Built-in condensate tray
• Tichelman system – maximum use of the exchanger surface
• Slat spacing: 3 mm
• Operating pressure: up to 1,0 MPa
• Maximum temperature of the agent: 110°C

Additional options:

• Air filter
• Possibility to adjust the radiator with 0 to 10 V signal using the Expansion module (control from AirPack air handling units)

Intended to cooperate with recuperators:

• AirPack4 300, 400, 500 h Energy + / Energy++ / Enthalpy
• AirPack4 300, 400, 500 v Energy + / Energy++ / Enthalpy
• AirPack4 550 v Energy + / Energy++
• AirPack Home 650, 850 h Energy +
• AirPack Home 600, 800 v Energy +
• AirPack Home 200f L / 200f Energy+

It also fits to earlier models of recuperators that are no longer available in the offer:

• AirPack Home 300, 400, 500 h Energy / Energy +
• AirPack Home 300, 400, 500 v Energy / Energy +
• AirPack Home 650, 850 h Energy
• AirPack Home 600, 800 v Energy
• AirPack Home 200f L / 200f Energy
