Wi-Fi elektros stebėjimo prietaisas MEW-01 MRP

Trumpai apie prekę

Prekė: Wi-Fi elektros stebėjimo prietaisas MEW-01 MRP. Kategorija: Jutikliai.

• Gamintojas: Zamel
• Modelis: MEW-01 MRP

MEW-01 MRP is a version of the Wi-Fi 3F+N electricity monitor, which is designed for use with MRP-200A and MRP-400A accessory transformers. It is used wherever it is necessary to extend the measuring range in relation to the standard 3x 100 A.

The highest standard of accuracy for monitoring electricity consumption available with advanced data analysis tools. MEW-01 is a device designed for mounting on a DIN rail (TH35), occupies the width of two modules and offers the possibility of attaching an external antenna for use also outside the switchgear. MEW-01 is a 3-phase and two-way monitor. It is therefore suitable for monitoring both energy consumed and transferred to the power grid. Wi-Fi connectivity means that it is not necessary to run new cables, and the collected measurement data is analyzed in the Supla* mobile application. MEW-01 is a device intended for installation inside, and after placing in an additional hermetic housing and protection against water ingress also outside the premises. *there is also the possibility of multidimensional analysis of data from multiple monitors using additional software

The device in the MEW-01 MRP version is sold without current transformers. We recommend choosing MRP-200 or MRP-400 modules with 200 or 400A transformers.

• WEIGHT: 0,05 kg
• DIMENSIONS: 9 × 3,5 × 6,6 cm
• BRAND: SUPLA
• POWER SUPPLY VOLTAGE [V]: 230/400
• ENERGY CONSUMPTION [W]: 1,5
• MEASUREMENT METHOD: Semi-indirect
• TYPE OF TRANSFORMERS: None
• RANGE [M]: WiFi networks
• NUMBER OF DIRECTIONS OF COMMUNICATION: 2
• CONNECTIVITY TYPE: WiFi
• WI-FI FREQUENCY [GHZ]: 2,4
• OPTICAL SIGNALING: YES
• LIGHT COLOR: Red
• COLOR: Green
• ASSEMBLY METHOD: TH35 (DIN rail)
• WIDTH IN MODULES [*17,5 MM]: 2
• MOBILE APPLICATION: supla – Android, supla – IoS
• DEGREE OF PROTECTION [IP]: 20
• OPERATING TEMPERATURE [°C]: -10÷+55

Basic features of the product:

• Wi-Fi communication - all our SUPLA products communicate over a wireless network. There is no need for additional access points or running new cables.
• Wide measuring range thanks to the use of available transformers (100 A, 200 A and 400 A).
• Measurement of electricity consumption and electricity, voltage, power on 3 phases.
• Possibility of multidimensional analysis of readings in the mobile application and Supla Cloud panel.
• Possibility of integration with company ERP software through API.
• Support MQTT communication standard.
• Option to export measurement data to csv, xlsx, ods and html formats.
• Ability to create individual PUSH notifications in the Supla app.
• Automatic reactions - the option to create automated processes initiated, e.g. exceeding the set voltage or power level.
