Apraksts
Trumpai apie prekę
Prekė: ZigBee valdiklis SMHUB Premium, suderinamas su MQTT, ZHA, Matter, Thread, Home Assistant. Kategorija: Centriniai blokai.
- Gamintojas: SMLIGHT
- Modelis: Centralka ZigBee multiradio SMHUB SMLight
Version: SMHUB Premium (CC2674P10 / EFR32MG24)
⭐SMHUB Premium – Intelligent Automation and Control System
SMLIGHT SMHUB Premium (CC2674P10 / EFR32MG24) is a modern device class smart home & automation gateway / hub – a central unit for managing a smart home, office or industrial space. Designed for stability, scalability and full control over IoT devices in one place.
Runs locally popular applications (m.in. Zigbee2MQTT, Mosquitto MQTT, Matterbridge, Node‑RED), so you can build a stable, fast and fully local smart home system – without the cloud and without additional bridges.
With built-in ZigBee and Thread and optional Z‑Wave and 4G/LTE, the SMHUB is suitable for both enthusiasts and advanced users, as well as for corporate, professional installations.
⭐ For whom?
- For people who want a simple start “out of the box”, but with full local control.
- For Home Assistant, OpenHAB, HomeSeer and other platform users, SMHUB can act as a standalone hub, Matter bridge to Apple/Google Home, or as a remote radio coordinator.
- For installers and businesses – when it comes to 24/7 reliability, flexible extensions and the ability to work offline.
NOTE: Full instructions for configuration and use can be found at:
https://bit.ly/3Ls3FqQ
⭐What is SMHUB?
SMHUB is a central control platform for intelligent automation, integrating various protocols and devices in one place.
⭐SMHUB-OS – a system designed to work
SMHUB-OS is a minimalist Linux-based operating system designed to:
- fast start-up and low resource consumption,
- stable operation 24/7,
- seamless integration with IoT devices,
- security and updates.
Thanks to this, the SMHUB operates smoothly, reliably and without “silting”, even with a large number of connected devices.
⭐Key advantages of the product
- Comprehensive connectivity: support for wireless standards like Zigbee / Thread / BLE (depending on configuration)
- High performance: premium processor (EFR32MG24 / CC2674P10)
- Continuous operation: stable Linux-based operating system
- Easy start: intuitive setup and integration with smart devices
- Flexibility: support for a wide range of sensors, relays, lighting, sockets, roller shutters, sensors, etc.
- Scalability of the solution: for small apartments for complex home and commercial installations
⭐Why SMHUB vs. Alternatives
- Local processing – works without the cloud
- Multi-radio in one device – guaranteed integration of Zigbee + Thread + Wi-Fi + BLE
- Expansion flexibility – optional modules (Z-Wave, LTE, PoE)
- High stability – no overloading of the system
- Scalability – from small installations to large projects
⭐Applications
- control of lighting and scenes
- sensor integration (movement, temperature, humidity)
- automatic blinds, gates
- Automation schedules and rules
- integrations with Home Assistant, OpenHAB, Google Home, Apple Home (via Matterbridge)
Specification
Main system
- CPU: 2 cores, 1 GHz + 700 MHz
- FRAME: 512 MB
- Memory: 8 GB eMMC
- microSD: yes, up to 2 TB
- System: Linux Kernel with modular application support
- Power supply: USB‑C (power + upstream) / optional PoE module / optional UPS connector
Radio communication
- Zigbee/Thread: CC2674P10 SoC
- Zigbee/Thread (second): EFR32MG24 SoC
- Wi‑Fi: Wi‑Fi 6, 2.4 and 5 GHz (integrated)
- Bluetooth: BLE 5.0 (integrated)
- Z‑Wave: optional via Z‑Wave module
- 4G/LTE: optional, via 4G/LTE module
Antenna
- Zigbee: 5 dB external antenna
- Thread: 5 dB external antenna
- Wi‑Fi: integrated via IPEX connectors, expandable up to 5 dB
- Bluetooth: integrated via IPEX connectors, expandable up to 5 dB
- Z‑Wave (optional): integrated by IPEX, expandable up to 5 dB
- 4G/LTE (optional): integrated by IPEX, expandable up to 5 dB
Network
- Ethernet: 1 × RJ45 (10/100 Mbps)
- Wi‑Fi: Wi‑Fi 6, 2.4/5 GHz
- VPN: support m.in. for WireGuard
- Local hosting: Zigbee2MQTT, Matterbridge, Node‑RED, Mosquitto
Ports and I/O
- USB: 1 × USB‑A (downstream), 2 × USB‑C (downstream), 1 × USB‑C (power + upstream)
- IR: IR transmitter – integrated; IR receiver – integrated
- Buzzer: integrated
- Ambilight: 12 × WS2812B (addressable RGB)
- Audio: 3,5 mm output
- User control: 3 × button + 4 × service diode
- Extensions*: DIY pins, optional space for third radio‑module
Additions and modules
- PoE 802.3af: optional module
- Z‑Wave 700/800: optional module
- 4G/LTE Cat‑1: optional module
- 5V UPS: optional device
Construction and working conditions
- Dimensions: compact, custom desktop enclosure
- Assembly: desk or wall (accessories)
- Operating temperature: 0 to 50 °C
- Cooling: passive (noiseless)
Software and integration
- Packages: Linux applications
- Preinstalled applications: Zigbee2MQTT, Matterbridge, Mosquitto MQTT, Node‑RED, WireGuard, NodeJS
- Management: Web interface
- Firmware: OTA updates
- Security: “local‑first”, encrypted connections
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Brand | SMLIGHT |
| Parametry | Series | ZigBee |
| Parametry | Kind | control switchboard |
| Parametry | Power supply | mains |
| Parametry | Manufacturer code | Centralka ZigBee multiradio SMHUB SMLight |
| Parametry | EAN (GTIN) | 5999572034269 |
| Parametry | Packaging status | original |
| Parametry | Batteries included | no |
| Parametry | Certificates of conformity | CE |
