Aprašymas
Trumpai apie prekę
Prekė: 4 kanalų imtuvas ELMES U4HR/24V, 24V. Kategorija: Išoriniai moduliai.
- Gamintojas: Elmes
- Modelis: U4HR
The U4HR receiver with four relay outputs is designed for alarm and remote control systems. It is made in the power supply version: 24V DC/AC. The device uses the KEELOQ(R) variable encoding system. They work with all remote controls and detectors and with the RP501 transmitter produced by Elmes Elektronik for the 434 MHz radio band.
Description of action
Activation of the remote control or other transmitter programmed into the receiver activates the relay at its output and turns on the corresponding LED. Depending on the set mode of operation of a given output, switching on lasts for a pre-programmed time (monostable mode), or until the remote control (transmitter) is used again, i.e. alternately in the cycle turn on / off the relay (bistable mode). This method of work applies to most types of transmitters. It is different in cooperation with the RP501 transmitter operating in radio relay mode or CTX3H and CTX4H detectors operating in open/close detection mode. In the case of these devices, regardless of the channel operating mode set in the receiver, the output remains on until it is turned off in the transmitter.
Features of the receiver:
operating frequency: 433,92 MHz, superheterodyne receiver,
4 galvanically separated relay outputs with a load capacity of 1A/128V,
two output modes, set independently for each channel: bistable and monostable,
on request a special version for the winch, in which the output is attached as long as the remote control button is pressed,
function of the mini control panel,
memory up to 112 transmitters.
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Kind | other |
| Parametry | Series | U4HR/24V Odbiornik 4-kanałowy 24V ELMES |
| Parametry | Brand | Elmes |
| Parametry | Manufacturer code | U4HR |
| Parametry | EAN (GTIN) | 5902052400546 |
| Parametry | Product weight with unit packaging | 0.1 kg |
| Parametry | Batteries included | no |
