4 kanalų stiprintuvas SOUNDMAX SX-LX4350.4D, 4×350 W RMS, D klasė

Trumpai apie prekę

Prekė: 4 kanalų stiprintuvas SOUNDMAX SX-LX4350.4D, 4×350 W RMS, D klasė. Kategorija: Stiprintuvai.

• Gamintojas: SoundMax
• Modelis: SX-LX4350.4D

⭐ EXTREME POWER AND FULL CONTROL OVER THE AUDIO SYSTEM

The Soundmax SX-LX4350.4D is a powerful 4-channel Class D amplifier designed for the most demanding car audio systems. It offers up to 4×350W RMS at 4Ω and 4×530W RMS at 2Ω, making it perfect for powering front, midrange, midbass or entire active audio systems.

The ability to work in the bridge allows you to get up to 2×1060 W RMS at 4 Ω, which makes it an extremely versatile amplifier for both SQ and SPL systems.

✅ Powerful 4×350W RMS at 4 Ω

✅ Stable operation at 2 Ω

✅ Bridge capability up to 2×1060 W RMS

✅ Class D – high efficiency and low heating

✅ High-Level Entry

✅ Compact and modern design

⭐ IDEAL FOR ACTIVE SYSTEMS AND POWERFUL FRONT SETS

The SX-LX4350.4D is equipped with extensive HPF, LPF filters and Band Pass mode, which allows you to perfectly match the work of each channel to a specific speaker.

The wide frequency response and low distortion ensure dynamic and clear sound even at very high volume levels.

✅ HPF 50-500 Hz filter

✅ LPF 50-250 Hz filter

✅ Band Pass Mode

✅ High-Level Entry

✅ Input sensitivity 0,25-8 V

✅ THD only 0,15%

⭐ TECHNICAL SPECIFICATIONS

Manufacturer

✅ Soundmax

Model

✅ SX-LX4350.4D

Type

✅ 4-Channel Amplifier

Operating Class

✅ D

Number of Channels

✅ 4

RMS Power

✅ 4 × 350 W RMS at 4 Ω

✅ 4 × 530 W RMS at 2 Ω

✅ 2 × 1060 W RMS at 4 Ω (bridged)

Filters

✅ HPF: 50-500 Hz

✅ LPF: 50-250 Hz

✅ Band Pass Mode

Parameters

✅ Frequency Response: 10 Hz – 45 kHz

✅ Input Sensitivity: 0,25-8 V

✅ Signal-to-noise ratio: 90 dB

✅ THD: 0,15%

Inputs

✅ RCA

✅ High-Level Input

Application

✅ Active systems

✅ Front sets

✅ Midbass

✅ Midrange speakers

✅ Bridge under subwoofers

⭐ FREQUENTLY ASKED QUESTIONS

❓ Can the amplifier be bridged?

Yes. After bridging, we obtain 2×1060 W RMS at 4 Ω.

❓ Does it have a High-Level entrance?

Yes. Thanks to this, you can also connect the amplifier to the factory radio.

❓ Is it suitable for active systems?

Yes. Thanks to HPF, LPF and Band Pass filters, it is perfect for complex active systems.

❓ Does the amplifier work at 2 Ω?

Yes. It offers 4×530 W RMS.

⭐ CONTENTS OF THE SET

✅ Soundmax SX-LX4350.4D amplifier

✅ User Manual

✅ Mounting elements

✅ Original manufacturer packaging
