Aprašymas
Trumpai apie prekę
Prekė: Adapteris SLZB-MR4U su ZigBee, Thread, PoE, USB, WiFi, LAN, CC2674P10, EFR32MG26, ESP32. Kategorija: Centriniai blokai.
- Gamintojas: SMLIGHT
- Modelis: SLZB-MR4U
⭐U Series
This is an improved edition of the flagship coordinators, introducing key hardware fixes for professional smart home installations:
- Hardware Flow Control: The introduction of hardware flow control for the radio system (SoC) eliminates errors in data transmission, significantly increasing stability under heavy network load.
- Native USB mode: The device can work as a classic USB "dongle", where the radio module is visible directly in the system (Native USB-series), which minimizes latency.
- USB-over-IP (Passthrough): A unique feature that allows remote access to other USB devices (e.g. ZWave) connected to the coordinator directly via LAN.
- Full customization: The new ESP32-S3 processor enables m.in. programmatic control of LEDs at the RJ45 socket.
⭐SLZB-MR4U – Multiradio Coordinator
✅ State-of-the-art radio chipsets: CC2674P10 and EFR32MG26
✅ Multiradio - ZigBee and Thread simultaneously
✅ Communication via USB, WiFi, Ethernet - PoE
✅ USB PassThrough (U Version): a solution for transmitting USB signal over Ethernet
⭐ Key features of SLZB-MR4U
- Unmatched performance – the latest and most powerful Zigbee/Thread chipsets on the market
- Industrial reliability – designed for demanding professional installations
- Maximum compatibility – full support for Zigbee2MQTT, ZHA, Home Assistant, OpenThread Border Router
- Plug & Play – pre-programmed device, ready to work out of the box
- SLZB-OS – advanced operating system with OTA updates, VPN support, over 20 languages
- Future-proof – full support for Matter-over-Thread and the latest IoT standards
⭐ SLZB-MR4U specification
- Radio Chipsets: CC2674P10 (TI), EFR32MG26 (Silicon Labs)
- Supported protocols: Zigbee 3.0, Thread (Matter-over-Thread), Ethernet
- Transmission power: +20 dBm (both radios) with built-in PA amplifiers
Memory:
- CC2674P10: 192 kB RAM, 1024 kB Flash
- EFR32MG26: 256 kB RAM, 2048 kB Flash
- Power Supply: PoE 48V (IEEE 802.3af), USB-C 5V DC
- Power consumption: up to 1,5 W
- Antennas: 2x SMA external (2,4 GHz) - top quality
- Connectors: USB-C, Ethernet RJ45
- Housing: ABS, ventilated, wall mounting/DIN/tape
- LED indicators: 6 independent LEDs (2 for each SoC)
- Button: Multifunction (mode change, reset, configuration)
➡ Specification
Texas Instruments CC2674P10
- Zigbee 3.0 support (compatible with Zigbee2MQTT [Z2M] and Zigbee Home Automation [ZHA])
- Thread support (Matter-over-Thread, compatible with Open Thread Border Router)
- State-of-the-art TI chip with maximum efficiency
- Transmission power +20 dBm with built-in PA amplifier
- 192 kB RAM, 1024 kB Flash
- Supports up to 400+ devices on the network
Silicon Labs EFR32MG26
- Zigbee 3.0 support (compatible with Zigbee2MQTT [Z2M] and Zigbee Home Automation [ZHA])
- Thread support (Matter-over-Thread, compatible with Open Thread Border Router)
- Silicon Labs' most powerful chip on offer
- Transmission power +20 dBm with built-in amplifier
- 256 kB RAM, 2048 kB Flash
- Advanced security and encryption features
Antenna
- Two external SMA antenna connectors (one for each radio SoC)
- Includes 2 high-end 2,4 GHz antennas
- Optimized for maximum coverage and stability
Power supply
- PoE power supply, IEEE 802.3af (48V) support
- Power supply via USB-C (5V DC)
- Low power consumption – up to 1,5 W (when both radio systems are operating)
- Stable power supply for continuous operation
Connectivity
- USB-C (power & data) with high-quality connector
- Stable Ethernet (LAN8720)
- 48V PoE for single-cable solution
- No WiFi for maximum connection stability
Housing and assembly
- Compact, industrial-grade ABS housing with ventilation
- Compatible with DIN rail and wall mounting
- Possibility of quick installation with double-sided tape
- Easy mounting on screws – mounting kit included
- Durable construction for long-lasting performance
SLZB-OS system
- Advanced web interface
- OTA updates for radio firmware and system
- Support for more than 20 languages
- Built-in VPN (WireGuard)
- Standalone Zigbee Hub mode
- Integration with Home Assistant
- Advanced diagnostic functions
The product was designed, developed and tested in Ukraine by SMLIGHT - a world leader in Zigbee/Thread technology.
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Brand | SMLIGHT |
| Parametry | Series | SLZB-MR |
| Parametry | Kind | control switchboard |
| Parametry | Power supply | mains |
| Parametry | Communication | ZigBee |
| Parametry | Additional features | WiFi connection |
| Parametry | Manufacturer code | SLZB-MR4U |
| Parametry | EAN (GTIN) | 5999572034214 |
| Parametry | Packaging status | original |
| Parametry | Batteries included | no |
| Parametry | Certificates of conformity | CE |
