Adapteris SMLIGHT SLZB-MRW10, PoE, Zigbee, Thread CC2652P, Z-Wave, multiradio

Trumpai apie prekę

Prekė: Adapteris SMLIGHT SLZB-MRW10, PoE, Zigbee, Thread CC2652P, Z-Wave, multiradio. Kategorija: Centriniai blokai.

• Gamintojas: SMLIGHT
• Modelis: SLZB-MRW10

⭐Revolutionary multiradio gateway SLZB-MRW10

Compact, powerful multiprotocol adapter, designed to integrate with Smart Home hubs, bridges and custom automation platforms. It serves as a reliable foundation for the development and testing of next-generation systems, combining support for Zigbee 3.0, Thread/Matter, Wi-Fi and Z-Wave networks (currently in the uncertified testing phase).

⚠ Important: This device is not Z-Wave certified. Z-Wave support on this device is for testing purposes only.

⭐Main features

• Zigbee and Matter-over-Thread: supports Zigbee 3.0 and Matter-over-Thread protocols
• Flexible connectivity: via Ethernet, Wi-Fi or USB
• PoE support: power over Ethernet (IEEE 802.3af standard)
• Compatibility with Home Assistant: works with ZHA, Zigbee2MQTT and other platforms
• Signal amplification: +20 dB amplifier and +5 dBi antenna for greater range
• Compact design: minimalist and discreet housing

⭐ ZigBee protocol

What distinguishes ZigBee from classic WiFi is a sufficiently long working time of battery-powered devices (unattainable with the classic WiFi protocol) and signal transmission through accessories powered by 230V.

In addition, selected ZigBee devices (230V mains powered) become part of the Mesh network. This means that if a module is unable to connect directly to the ZigBee gateway, it communicates with it through another closest accessory of this system. The repater in the ZigBee ecosystem are devices powered by 230V, such as PSMART, Aqara T1, OXT Zigbee relay, Sonoff ZBMINI, TUYA, 230V sockets or bulbs.

Thanks to this, you can create an extensive network that can operate over much longer distances than classic WiFi.

⭐Matter – the new Smart Home standard

Matter is a universal communication standard that makes smart home devices from different manufacturers work together in one network. Matter provides reliability, security, and local control of devices without the need for the cloud.

The most important features of Matter:

• Universality: Collaboration of devices of different brands in one ecosystem.
• Security: End-to-end encryption protects your data.
• Integration: Compatible with Amazon Alexa, Google Home, Apple HomeKit, and Samsung SmartThings.
• Ease of configuration: Quick pairing via QR code or NFC.
• Local control: Most functions work even without an internet connection.

The perfect choice for a modern and comfortable smart home!

⭐ Specification

• Chipset: Texas Instruments CC2652P (Zigbee/Thread), dual-core ESP32 240 MHz
• USB/UART: CP2102N (Silicon Labs)
• Ethernet: LAN8720 (Microchip), 10/100 Mb
• Antenna: L-shaped external +5 dBi (Baishi), internal Wi-Fi/Bluetooth antenna
• Power Supply: USB-C or PoE IEEE 802.3af (48 V)
• Power consumption: 1,5 – 3 W
• Radio output gain: to +20 dB
• Working modes: Zigbee coordinator (ZHA/Z2M), Zigbee router, Matter-over-Thread router, Zigbee standalone hub
• Integration: Zigbee2MQTT, ZHA, Home Assistant
• Bluetooth support: Yes
• Flasher ESP32: integrated, autoboot via DTR/RTS
• Dimensions (adapter): 160×24×28 mm, 86 g
• Dimensions (antenna): 192×12×12 mm, 15 g
• Pack size: 180×25×40 mm
