Automobilinis stiprintuvas Axton A894DSP

Trumpai apie prekę

Prekė: Automobilinis stiprintuvas Axton A894DSP. Kategorija: Stiprintuvai.

• Gamintojas: Axton
• Modelis: Axton A894DSP

AXTON A894DSP - 8.1 Channel DSP Processor Amplifier, Car Power Amplifier with Digital Sound Processor, 6 Input Channels, Mobile Phone App Control, Bluetooth Audio Streaming, Pre-installed Presets for ATS-ISO8*** PnP Cable Harnesses

The compact 8.1-channel SMART DSP A894DSP amplifier is the perfect upgrade for many factory-integrated sound systems.

All in to Win

Six high-level inputs and matching optional plug & play cables allow you to connect not only to standard sound systems, but also to a wide range of partially and fully active car audio systems. The high practicality of the A894DSP is already evident in the input section: input channels can be distributed, split or combined with output channels with full flexibility. Most importantly, the input equalizer can even be used to linearize the music signal if required.

Extensive BTL (bridge mode) modes offer a flexible choice of output channels, e.g. 8.0, 6.1, 4.2 or even 4.1 with up to 400W RMS @ 2 Ohm for subwoofer. The individualized signal is conveniently transmitted to a separate subwoofer or central amplifier via a dual mono RCA output or optical output.

Take control

The integrated digital sound processor enables wide audio settings per channel, such as delay time correction, freely configurable frequency filters (6/12/18/24 dB in three selectable Butterworth, Bessel and Linkwitz-Riley characteristics), gain control and 31-band parametric equalizer. Configurations (channel routing and crossover frequency pre-setting) for each of the optional vehicle-specific Plug & Play connection cables are also integrated into the app.

Bluetooth and more

The integrated Bluetooth audio streaming interface makes it easy to stream your own music collection to the amplifier. The A894DSP also offers the option to play Hi-Res Audio music data using the separately available ABT50 streaming interface. Thanks to optical inputs and outputs, several AXTON DSP amplifiers can be connected to each other without loss. The separately available A592DSP-RC remote control can be connected to the A894DSP.ÿ

MAIN FEATURES

• 8.1-Channel Smart Class-D Amplifier with DSP Audio Controlled Features via iOS or Android Apps
• 6-channel high-level input for easy connection to multi-channel OE sound systems with amplifier
• Preamplifier output with dual mono DSP control (5 V), including remote output for controlling additional amplifiers
• 6-Channel RCA Input
• Optical and coaxial input for high-definition audio streaming interface ABT50 or other AXTON SMART DSP amplifier with optical output
• Optical output for connecting the signal to another AXTON SMART DSP amplifier with optical input
• Bluetooth audio streaming with automatic source switching
• Plug & Play installation with optional vehicle-specific connection cables
• Automatic switch-on function by high level input

SETTING OPTIONS

• Freely adjustable active crossover: High/low/band/bypass with 6/12/18/24 dB/oct inclination. per channel
• Selectable filter characteristics: Butterworth, Bessel or Linkwitz-Riley
• Adjustable delay correction per channel: 0 - 550 cm / 0 - 15,8 ms
• Gain, phase switch, mute function per channel
• Freely configurable 31-band parametric equalizer per channel
• Freely configurable 9-band parametric equalizer per input source
• Memory locations for your own settings: 5 on the amplifier, unlimited on your smartphone
• Dynamic bass and treble function
• Noise gate function to reduce radio background noise

TECHNICAL DATA

• RMS output power at 4 ohms: 8 x 60 W
• RMS output power at 2 ohms: 8 x 75 W (8x 80W Effective)
• RMS output power of BLT4.2 CH 5+6 / CH7+8 @ 4 ohm mode: 2 x 230 W
• RMS output power of BLT4.1 CH 5+6+CH7+8 @ 4 ohm mode: 1 x 230 W
• RMS output power in BLT4.1 CH 5+6+CH7+8 @ 2 Ohm mode: 1 x 400 W
• Playback Range: 20 Hz ~ 20 kHz
• Dimensions: 238 x 180 x 50 mm

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With a VAT invoice
Parametry	Brand	Axton
Parametry	Model	Axton A894DSP
Parametry	Number of channels	other
Parametry	Amplifier class	D
Parametry	Product weight with unit packaging	1.8 kg
Parametry	Manufacturer code	Axton A894DSP
Parametry	Impedance	2 Ω
