Automobilinis stiprintuvas EDGE EDBX150.4, 4 kanalai, 4x100W RMS / 2x300W prie 4Ω

Trumpai apie prekę

Prekė: Automobilinis stiprintuvas EDGE EDBX150.4, 4 kanalai, 4x100W RMS / 2x300W prie 4Ω. Kategorija: Stiprintuvai.

• Gamintojas: Edge
• Modelis: EDBX150.4

⭐ POWERFUL AB CLASS AMPLIFIER FOR CAR AUDIO SYSTEM EXPANSION

EDGE EDBX150.4 is a high-end 4-channel amplifier designed for people who expect powerful, dynamic and clear sound. Thanks to Class technology, the AB offers natural sound, high working culture and high power for both speakers and after bridging – for the subwoofer.

The most important advantages

✅ Power 4 × 100 W RMS at 4 Ω

✅ Power 4 × 150 W RMS at 2 Ω

✅ 2 × 300 W RMS in bridge

✅ Class AB technology

✅ High Input

✅ Auto Turn On feature

✅ Built-in cooling fan

✅ Extended LPF / HPF filters

⭐ EDGE DBX – POWER, CONTROL AND EXCELLENT SOUND

The DBX series is equipped with a modern radiator with ribs in the shape of the letter T, which effectively dissipates heat even during long-term operation with high power.

The built-in cooling fan further stabilizes the amplifier temperature, and the wide range of filter adjustments allows you to fine-tune your entire Car Audio system.

Technical data

✅ Model: EDGE EDBX150.4

✅ Type: 4-Channel Amplifier

✅ Working class: AB

✅ RMS Power @ 4 Ω: 4 × 100 W

✅ RMS Power @ 2 Ω: 4 × 150 W

✅ RMS power in bridge @ 4 Ω: 2 × 300 W

✅ Maximum power: 1200 W

✅ Frequency Response: 20 Hz – 20 kHz

✅ Filters: LPF / HPF / Full

✅ Filter adjustment range: 30 – 250 Hz

✅ High Input

✅ Automatic Turn On (Auto Turn On)

✅ Built-in cooling fan

✅ Recommended protection: 2 × 25 A

Dimensions

✅ Compact housing for easy installation in most vehicles.

⭐ SET CONTENTS AND FREQUENTLY ASKED QUESTIONS

Included you get

✅ EDGE EDBX150.4 amplifier

✅ Operating instructions

✅ Mounting elements

Frequently Asked Questions

Does the amplifier work with the factory radio?

Yes. Thanks to the High Input input and the Auto Turn On function, it can be connected to most factory radios.

Can I power the subwoofer with it?

Yes. Once the channels are bridged, the amplifier offers 2 × 300 W RMS at 4 Ω, making it ideal for powering one or two subwoofers.

Is it suitable for powering the front and rear sets?

Yes. Four independent channels allow you to power a set of speakers in the car or configure the front + subwoofer system.

What are the advantages of class AB?

AB class amplifiers offer a very natural, warm and detailed sound, which is why they are valued by people who focus on high sound quality.
