Automobilinis stiprintuvas EXCURSION HXA-1K, 1 kanalo, 600 W RMS, 2 Ohm

Trumpai apie prekę

Prekė: Automobilinis stiprintuvas EXCURSION HXA-1K, 1 kanalo, 600 W RMS, 2 Ohm. Kategorija: Stiprintuvai.

• Gamintojas: Excursion
• Modelis: HXA-1K

⭐ EXCURSION HXA-1K – MONOBLOCK 600 IN RMS TO SUBWOOFER

The Excursion HXA-1K is a compact, 1-channel Class D car amplifier designed primarily for subwoofer power. It offers 400 W RMS at 4 Ω and 600 W RMS at 2 Ω, while maintaining small enclosure dimensions – only 140 × 54 × 200 mm.

The amplifier is equipped with High Level / Low Level inputs, so it can work with both RCA-equipped radio and the factory audio system.

The Auto Turn On/Off system offers as many as three ways to start the amplifier: classic REM +12 V, DC voltage detection on the speaker signal and automatic start-up when the AUDIO signal is detected.

The HXA-1K has an adjustable LPF low-pass filter, Subsonic filter and Bass Boost 0 to 12 dB, thanks to which it allows you to precisely adjust the subwoofer operation to the housing used and the entire Car Audio system.

An additional advantage is the Bridge-Link function, which allows you to connect two HXA-1K amplifiers in the Master/Slave system and obtain up to 1200 W RMS at 4 Ω.

✔ Power 600 W RMS at 2 Ω

✔ Power 400 W RMS at 4 Ω

✔ Digital class D

✔ Stable operation up to 2 Ω

✔ High Level / Low Level

✔ Auto Turn On/Off – REM / DC / AUDIO

✔ Adjustable LPF 40 – 200 Hz

✔ Adjustable Subsonic 0 – 50 Hz

✔ Bass Boost 0 to 12 dB @ 45 Hz

✔ Bridge-Link function

✔ Possibility to obtain 1200 W RMS / 4 Ω with 2 amplifiers

✔ Compact dimensions 140 × 54 × 200 mm

⭐ TECHNICAL SPECIFICATION EXCURSION HXA-1K

✅ Producer: Excursion

✅ Model: HXA-1K

✅ Type: monoblock / 1-channel amplifier

✅ Working class: D

✅ Technology: SMD / Full MOSFET

✅ Number of channels: 1

✅ RMS power at 4 Ω: 1 × 400 W

✅ RMS power at 2 Ω: 1 × 600 W

✅ Minimum Impedance: 2 Ω

✅ Bridge-Link – 2 × HXA-1K at 4 Ω: 1 × 1200 W RMS

✅ Frequency Response: 5 – 300 Hz

✅ THD at 4 Ω: < 0,3%

✅ Signal-to-noise ratio: >100 dB

✅ LOW Level Sensitivity: 0,2–5 V

✅ High Level Sensitivity: 0,6 – 15 V

✅ LPF filter: 40 – 200 Hz

✅ HPF / Subsonic filter: 0 – 50 Hz

✅ Bass Boost: 0 – 12 dB @ 45 Hz

✅ Efficiency at 4 Ω: >80%

✅ Operating voltage: 10 – 15 V

✅ Control: REM / DC / AUDIO

✅ Auto Turn On/Off: yes

✅ Bridge IN: 1 × RCA

✅ Bridge OUT: 1 × RCA

✅ Thermal protection: from 80°C

✅ Overload protection: yes

✅ Short-circuit protection: yes

✅ Voltage protection: yes

✅ External fuse required: 60 A

✅ Optional remote control socket: Excursion HXA-RC

✅ Dimensions: 140 × 54 × 200 mm

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With a VAT invoice
Parametry	Brand	Excursion
Parametry	Model	HXA-1K
Parametry	Number of channels	1-channel
Parametry	Amplifier class	D
Parametry	Product weight with unit packaging	2 kg
Parametry	Manufacturer code	EX-061
Parametry	Rated RMS power	600 W
Parametry	Impedance	2 Ω
Parametry	THD distortion	0.2%
Parametry	Signal-to-noise ratio	100 dB
Parametry	Packaging status	original
