Automobilinis stiprintuvas JL Audio RD500/1, 1 kanalo, monoblokas, klasė D, 500 W

Trumpai apie prekę

Prekė: Automobilinis stiprintuvas JL Audio RD500/1, 1 kanalo, monoblokas, klasė D, 500 W. Kategorija: Stiprintuvai.

• Gamintojas: JL Audio
• Modelis: RD500/1

JL Audio RD500/1 - 1-channel amplifier / class D monoblock with 1x 500 W power at 2 Ohm / 1x 250 W at 4 Ohm.

New, pre-packaged.

The 500W RD500/1 amplifier at 2 ohms (14,4V, 1% THD) is designed to generate tons of pure subwoofer pleasure in a sleek, ultra-compact design. The secret of its power is our patented NexD™ switching technology, which provides high power output with precise performance and very low distortion.

The look is amazing and great performance is added value. In the RD series uniform amplifiers from JL Audio, the exclusive NexD™ switching technology generates plenty of power with exceptional performance. The result: the highest sound quality with significantly reduced power consumption and heat release.

Made in USA

You buy in a reputable Car Audio store from an authorized dealer of the JL Audio brand in Poland, original products with a Polish guarantee.

RD Series

Clean, efficient and reliable

In the RD series you will find a variety of models to drive the subwoofer – available in 500- or 1000-watt (stable up to 2 Ω) or 1500-watt (stable up to 1 Ω) versions. The high-performance design allows them to work in cooler environments and put less strain on the electrical system than conventional amplifiers.

Efficient class D design

Small size, minimal heat and high power - the design of the Class D amplifier provides significant benefits. And our NexD switching technology adds even more, using improved pulse width modulation techniques, to increase the bandwidth of the amplifier while minimizing distortion and improving performance.

Studio-grade signal processing

In order to facilitate configuration and cooperation with the system speaker, the RD series devices are equipped with a 12 dB/octave low-pass filter with smooth frequency control in the range of 50 - 500 Hz and variable bass boost equalizer.

LED indicator

This all-new, innovative feature allows you to easily set the input sensitivity of your amplifier, quickly and accurately, without the need for special equipment. The RD500/1 features a durable, black powder coated finish and a top mounted two-tone LED light bar that informs you of your overall condition and fitness. With the addition of the RBC-1 remote level controller (sold separately), you can control the subwoofer output directly from the driver's seat.

Auto-on function

This useful feature, thanks to which you can choose between signal detection and DC offset modes, is standard in all amplifiers of the RD series.

NexD technology

Using improved pulse width modulation techniques, NexD technology achieves exceptional sound fidelity and performance while delivering high power output from amplifiers with very compact designs.

Sustainable differential inputs

To solve the problem of cable interference, this technology enables the use of conventional RCA cables, providing the benefits of a truly balanced connection and compatibility with a wide range of input signal levels.

Specification:

• 1-Channel / Monoblock Amplifier
• Class D
• RMS power at 2 Ohms: 1x 500W
• RMS power at 4 Ohms: 1x 250W
• Signal-to-noise ratio: >80 dB
• Signal-to-noise ratio at 1W: >60 dB
• Attenuation factor at 4 Ohm: >1000/50 Hz
• Attenuation factor at 2 Ohms: >500/50 Hz
• THD+N at rated power: < 1% at 2 Ohms
• Frequency Response: 7 Hz-500 Hz
• Fuse: 30A
• Recommended fuse type: FS, AGU or MaxiFuse
• Filter mode: channels 1 and 2 only low-pass
• Bass boost
• Low tone gain equalizer (0 to +12 dB at 45 Hz)
• Dimensions (H) x W x D. ): 54 x 248 x 177 mm

Included:

• Amplifier
• Allen key with a diameter of 2,5 mm
• Label JL Audio

OUR OFFER INCLUDES AND AVAILABLE ALL JL AUDIO MODELS, OF COURSE NEW FROM THE POLISH DISTRIBUTION NETWORK.
