Automobilio šildytuvas su ventiliatoriumi PTC 24V 180W

Trumpai apie prekę

Prekė: Automobilio šildytuvas su ventiliatoriumi PTC 24V 180W. Kategorija: Oro šildytuvai.

• Gamintojas: no brand
• Modelis: JYA02252

Features:

1. With insulator on the surface, safe to use, high reliability.

2. It heats up quickly, long service life. With mounting holes, easy to install.

3. It adopts heat-resistant silicone wire as guide wire, red wire for "+" and black wire for "-".

4. This system is energy efficient, when the heater increases the ambient temperature, the power will gradually decrease in certain ranges.

5. Applicable to heater, humidifier, air conditioning and other commonly used appliances.

Technical data:

Colour black

Optional Type: Rated Voltage: 24V Rated Power: 180W (10A)

Mounting hole distance: approx. 87mm/3.4"

Mounting hole diameter: approx. 4mm / 0.16"

Product Size: approx. 60 x 60 x 42 mm / 2,4" x 2,4" x 1,7"

Ambient temperature range: -5 ~ 65 ℃

Package weight: approx. 160g

Quantity: 1 piece

The package includes:

1 x PTC Heater

Product manual of PTC series air heater with fan:

1. When bare wire protrudes from the heater, the positive and negative electrodes are not distinguished. Enter the rated voltage and sufficient current.

2. When an unshielded wire protrudes from the fan, red is a positive electrode and black is a negative electrode. Enter the rated voltage and sufficient current.

3. The heater can be used in a very humid air environment. It does not matter if a small amount of water droplets splash on the surface of the heater, but they can not be submerged

fluid.

4. The insulation of the black radiator bracket is resistant to high temperatures, but the metal part is conductive. Please pay attention to safety during use.

5. The life of the heater fan is 3~5 years, 20000~30000 hours.

6. The heater is equipped with a 230℃ chip. When the fan blows, the surface temperature of the heater is about 100 ℃. When the fan breaks down and stops rotating, stop using

heater to avoid potential safety hazards.

7. When the heater is used for the first time, a small amount of smoke or odor may appear, which is caused by the oil stain and the leakage of the heat conductive adhesive left by the pressing of aluminum corrugations. This is normal and will disappear in a short time.

8. The power of the product is related to the mode of use, heat dissipation conditions, ambient temperature and other factors. The rated power we provide refers to the power measured in

ambient temperature 24 ℃. Under these conditions, the air temperature at a distance of 5 cm from the outlet is about 50 ℃ Celsius. (when the ambient temperature drops, the heater power will be

increase. )

9. When used in a small, enclosed space, after a certain period of operation, when the ambient temperature near the heater rises, the energy consumption of the heater will gradually decrease, which is an energy-saving feature of the PTC products themselves.

10. Safety, stability, energy saving, environmental protection and long service life are the most important advantages of PTC products. Normal use from 5000 to 10000 hours, power attenuation is about 15%. (Unlimited switch times)

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	no brand
Parametry	Kind	electric
Parametry	Model	JYA02252
Parametry	Product weight with unit packaging	0.5 kg
Parametry	Manufacturer code	cd4418cb-69d1
Parametry	Packaging status	original
Parametry	Energy efficiency class	A
Parametry	Range of energy efficiency classes	A++ - G
