Dulkių filtras M5 / ePM10 55%, 180 x 400 x 25

Trumpai apie prekę

Prekė: Dulkių filtras M5 / ePM10 55%, 180 x 400 x 25. Kategorija: Dalys.

• Gamintojas: Murano Feniks
• Modelis: 18188344

Murano Phoenix

• Air filter type: Harmonic minipleat
• Filtration efficiency range: Anti-pollen
• Filter material used: Glass microfibers
• Filter class EN779: 2012: EU5 / M5
• Filtration standard DIN EN ISO 16890: ePM10 55%
• Filter Frame Type: Film Coated Waterproof Carton
• Air filter size list: 180*400*25mm, 400*180*25mm
• Brand Model of the air handling unit: Frapol Onyx Pride 400, Frapol Onyx Sky 500, Frapol Onyx Premium 500, Frapol Onyx Compact 500, Frapol Onyx Compact 750, Frapol Onyx Dream 400, Frapol Onyx Sky 1000

Fine pleated filter

M5 ePM10 55% 180 x 400 x 25 mm

Manufacturer Name Murano Feniks : MF/MPT/WRD M5 EPM10 55% 180x400x25 mm

A pollen filter with a cardboard frame for indirect filtration in mechanical ventilation, recuperation and air conditioning units. The structure of the filter is made of glass microfibers, finely pleated in minipleat technology, separated by hot melt separators that allow for the formation of rigid plithes. The filter pack is then glued tightly to the cardboard housing. A fine accordion allows the maximum use of the frame volume by obtaining the largest filtration area, ensuring maximum filter operation. Glass microfiber filter paper with increasing density at the air outlet side of the filter provides very low resistance during the entire period of filling the filter with impurities. The anti-pollen cassette filter, finely pleated, in the filtration packets in the M5 filtration class with the ePM10 efficiency of 55% in the dimensions of 180x400x25 mm, allows the capture of 55% of intermediate particles from the air, i.e. spores, cement dust and other contaminants less than 10 μm (micrometers). We include it among medium filters. Thus, this filter allows for medium air filtration in mechanical ventilation systems with heat recovery, called recuperation. Our filters are made of materials that meet high energy classes to ensure the lowest possible consumption of electricity by your recuperator.

Technical data:

M5 / EU5 ePM10 minipleat cassette filter 55%

Dimensions:

• Width: 180 mm
• Length: 400 mm
• Frame depth: 25 mm

Parameters:

• Filter material: glass microfiber insert

• Frame type: foil-coated waterproof cardboard

• Filter class according to EN 779: 2012: M5

• Filter class according to ISO 16890: ePM10 55%

• Maximum working temperature: <80 ° C

Filter material:

• Glass microfiber insert. Formed into filtration packets in the minipleat technology with hot melt separators.

Construction:

• Completely sealed construction.

• Insert glued in a cardboard frame.

• Increased filtering surface allowing longer filter operation.

Application:

• Filter used in places where high air purity is required, eg. pharmaceutical, electronic, medical and food industries.

Properties:

• Glass microfiber insert

• Anti-pollen

• Very large filter surface

• High performance

• Low operating costs

• Long service life

• High temperature resistant

• Standard and special sizes

• Filters are made in accordance with the requirements of the ISO 9001 Quality Management System, which ensures that the product maintains the highest quality at all times.

The air supplied by the ventilation, air-conditioning and recuperation systems is as clean as the filters cleaning them, and therefore the quality of the filters, their reliability and durability have a huge impact on the operation of the entire ventilation system and the quality of the air supplied by it.

Intermediate filter with a cardboard frame for a mechanical ventilation unit, dimensions 180x400x25 mm, filtration class m5 eu5 with ePM10 efficiency 55%. Providing air pollen filtration at home, office and business. Filter finely pleated in minipleat technology to provide the largest filter surface with a cardboard frame and a glass tissue cartridge with high efficiency in capturing impurities. Pollen filter to meet the level of indirect air filtration in mechanical ventilation, recuperator.

Murano Phoenix 18188344

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	Murano Feniks
Parametry	Kind	filter
Parametry	Product weight with unit packaging	5 kg
Parametry	Manufacturer code	18188344
Parametry	Batteries included	no
