Dvikanalinis mini jungiklis Sonoff MINI-ZB2GS ZigBee

Trumpai apie prekę

Prekė: Dvikanalinis mini jungiklis Sonoff MINI-ZB2GS ZigBee. Kategorija: Automatizavimo moduliai.

• Gamintojas: Sonoff
• Modelis: MINI-ZB2GS

Sonoff MINI-ZB2GS is a compact, two-channel smart switch based on the Zigbee 3.0 protocol, with which you can not only control the lighting, but also strengthen the range of the entire Zigbee network in your home. The small size (only 60 mm in diameter) allows for discreet installation behind most wall switches, while the support for two independent loads up to 16A ensures versatility in applications. The device acts as a Zigbee router, expanding network coverage and providing a stable connection to other devices. It also works with popular platforms such as eWeLink, Home Assistant (via ZHA or Zigbee2MQTT) and many Zigbee hubs. Control traditional buttons, through the app, create smart scenes and enjoy full control over lighting in any room.

• Manufacturer: Sonoff
• Model: MINI-ZB2GS
• MCU: EFR32MG21
• Power supply / electrical parameters: 110-240V~ 50/60Hz 10 A / channel max. 16 A total (resistance load)
• Zigbee: IEEE 802.15.4
• Dimensions: 45 × 39,4 × 16,8 mm
• Weight: 36,2 g
• Color: white
• Housing material: PC
• Certificates: CE/FCC/RoHS

• Dual Channel Mini Switch Sonoff MINI-ZB2GS ZigBee
• User manual

With the latest Zigbee 3.0 standard, the switch ensures reliable communication and low power consumption. It requires a Zigbee hub (sold separately), such as ZBBridge-P, ZBBridge-U, NSPanel Pro, iHost or popular USB dongly (ZBDongle-P/-E, Dongle-M, Dongle Plus MG24, Dongle Lite MG21). With the open Zigbee 3.0 protocol, you can easily integrate it into open-source platforms and create a smart home system tailored to your needs. The MINI-ZB2GS also acts as a Zigbee router, which actively amplifies the signal and extends the network range. Each installed device acts as a relay point, allowing sensors and other Zigbee devices in remote rooms to maintain a stable connection to the hub. It is ideal for larger homes and apartments where the range of a single hub may be insufficient.

The relay allows you to control two different light sources or devices from one place. It is perfect for living rooms with several light points or kitchens, where you want to control the main and under-cabinet lighting separately. Each channel supports up to 10A (16A in total), which is enough even for larger lamps or LED lighting. The device works with bistable, monostable and SPDT switches, offering full freedom of arrangement.

The device is compatible with the eWeLink application, offering full access to advanced features such as schedules, switching modes, and Detach Relay settings. Lovers of open-source solutions will appreciate the native integration with Home Assistant via Zigbee Home Automation (ZHA) or Zigbee2MQTT (Z2M), which allows you to create advanced automations and full control over the device without the manufacturer's cloud.

Create personalized automation scenarios tailored to your daily routines. The light can turn on automatically when motion is detected (requires a Zigbee motion sensor, e.g. SNZB-03P, sold separately and Zigbee hub), turn off when you leave the house, or light up the hallway at a specific time.

Enable Detach Relay mode to separate the operation of the physical button from the power control. The wall switch then becomes a smart trigger that can control the light scenes in Zigbee smart bulbs without interrupting their power supply. Note: The feature requires a Zigbee hub to operate.

With customizable on options, your device can remember the last state, automatically turn on, or stay off when power returns. Your smart devices will behave exactly the way you want them to, providing convenience and peace of mind after power outages or installation resets.

The PC flame retardant housing, overheating and surge protection and the EFR32MG21 chip with ceramic antennas ensure long-lasting, stable performance and enhanced signal. Despite its compact dimensions (45 × 39,4 × 16,8 mm), the device supports a total load of up to 16A. Installation possible in flush-mounted boxes type 86, EU and 120 (minimum depth 60 mm). The product is CE/FCC/RoHS certified.

Specifications
