Dyzelinis generatorius TAGRED, 7350 W, 1 fazės, 10 AG, tylus, su alyva

Trumpai apie prekę

Prekė: Dyzelinis generatorius TAGRED, 7350 W, 1 fazės, 10 AG, tylus, su alyva. Kategorija: Elektros generatoriai.

• Gamintojas: Tagred
• Modelis: TA7350DS
• Įtampa: 230 V

Advantages

⚡MAXIMUM GENERATOR POWER increased: 230V 5kW

⚡ Reinforced engine of Japanese construction with 7350 W(10hp)

⚡ Working comfort: additionally muted

⚡COPPER stator winding

⚡LATEST VERSION OF AVR Electronic Voltage Stabilizer

⚡Safe, IP23

The professional single-phase Tagred TA7350DS power generator is powered by a high-end high-power diselian motor. It is a reliable solution that will protect the farm, company, perfect for construction sites. It will easily power tools, construction machinery (betony machine, welding machine), lighting, many types of electrical equipment.

The unit has AVR (Automatic Voltage Regulation) protection, which prevents voltage fluctuations when changing load.

The muted generator housing with reduced noise emission provides greater comfort of use. A big advantage is the mobility of the generator, which has castors.

It cannot be overestimated that the TAGRED generator is equipped with candle heating and a relaxer for easy start-up.

The built-in glow plug in the intake system makes it easier to start the unit during low temperatures, allows you to work in difficult conditions!

Multitasking

The diesel generator set TAGRED generates a current of 230V. The generator set has 2 sockets: 2 x AC 230V. Thanks to them, you can power several different machines, even in parallel. The rated current is 21A/230W. It is useful in all places without access to electricity, e.g. on construction sites, open spaces, etc.

Solid, powerful engine

A 1-cylinder , 4-stroke diesel engine with a powerful output of up to 10 HP, equipped with an electric start , guarantees reliable use!

Copper motor windings!

The generator - stator and rotor, are made of the highest quality copper with very good electrical conductivity

This resulted in better work efficiency and reliability, and the operating time of the device was significantly extended.

The steel housing of the generator was additionally muted - from the inside glued with a soundproofing mat.

Startup: E-Start from the ignition

The generator is started by automatic start-up, using a key. The set includes a 20 Ah starter power battery.

Safety of operation provides a degree of protection IP23 and overload protection.

Our unit has additional oversized protections. Here we see a silencer with thermal protection

Composition of the set

• Generator set Diesel TAGRED
• 2 Liter Mobil Super Oil Bottles
• Accessories
• User manual in Polish

Technical data

• Model: TA7350DS
• Engine displacement: 418 cc
• Engine power: 10 HP / 7350 WATT
• Rotary speed: 3000 rpm. /min
• Engine type: 1-Cylinder Diesel
• Start: E-Start from the ignition
• Fuel: diesel
• Oil: 15w40
• Fuel tank capacity: 16 L
• Oil tank capacity: 1,75 L
• Built-in fuel level viewfinder
• Built-in voltage indicator: Voltmeter
• Generator capacity: 230V 4,2 kW / 5,25 kVA
• Max. Performance in W: 230V 5 kW / 6,25 kVA
• Socket: 2 x 230V / 50 Hz
• Permanent current: 12V / max. 8,3 A
• Power factor: cos φ1
• Mute generator housing: steel, glued from the inside with soundproofing mat
• Starter battery: 20 Ah
• Power factor: cos φ1
• Protection rating: IP23M
• Socket "ATS" - YES
• Type of generator winding: copper
• Acoustic power level in dB (A): 97
• Large transport wheels built into the housing: 4 pcs
• Hands: transport
• Weight: 150 kg
• Overall dimensions: 900x545x765 mm
• Package Dimensions: 900/545/700 mm
