Elektrinė oro užuolaida Reventon AERIS 100E-1P 230V

Trumpai apie prekę

Prekė: Elektrinė oro užuolaida Reventon AERIS 100E-1P 230V. Kategorija: Oro užuolaidos.

• Gamintojas: Reventon
• Modelis: AC100E1P
• Galia: 6 W

Producer: Reventon

Condition: new

Packaging: original

Origin: official distribution

Warranty: manufacturer

Electric air curtain Reventon AERIS 100E-1P 230V

The device from the AERIS series is a proposal dedicated to commercial facilities and public buildings, where the flow of customer traffic is very large. The device is designed to be mounted above or along the entrance door of the room. The curtain is equipped with electric heaters that heat the air flowing through it. It is therefore designed to be connected to the electrical network of the object. During operation, the air curtain creates a barrier to prevent heat loss through the open door, and also protects the room from insects and dust.

Application

The Reventon AERIS 100E-1P 230V electric air curtain is designed for installation in places where doors are opened and closed with high frequency. These are m.in.:

• shops,
• shopping malls,
• hairdressing establishment,
• restaurants,
• hotels,
• airports,
• public places of interest.

Parameters

Range: 3 m

Weight: 15,5 - 26 kg

Housing: metal, powder coated

Additional information:

• The curtain is available in three sizes: 100 cm, 150 cm and 200 cm.

Control

• Possible control via remote control or using a door sensor.
• Two-stage fan speed control.
• The air curtain includes a door sensor and mounting panel, as well as a remote control.

Advantages

• ergonomics of the device,
• effective protection against dust and insects from the outside,
• solid plastic housing,
• remote control included,
• easy installation,
• contemporary design.

Technical data

AERIS 100E-1P AERIS 150E-1P AERIS 200E-1P Product code AC100E1P AC150E1P AC200E1P Heater power [kW]

heating stage 3/2/1

6,0 / 4,0 / 2,0 10 / 6,7 / 3,3 14 / 9,4 / 4,6 Rated current [A]

heating stage 3/2/1

26,1 / 17,4 / 8,7 43,5 / 29,1 / 14,3 60,9 / 40,9 / 20 Maximum airflow [m3/h]

2 gear/1 gear

1200 / 1100 1900 / 1700 2800 / 2500 Maximum air speed [m/s]

2 gear/1 gear

8,5 / 7,5 8,5 / 7,5 8,5 / 7,5 Voltage/Frequency [V/Hz] 230/50 230/50 230/50 Rated motor current [A]

2 gear/ 1 gear

0,78 / 0,57 1,00 / 0,78 1,52 / 1,30 Engine power [W]

2 gear/ 1 gear

180 / 130 230 / 180 350 / 300 Degree of protection IP E / IP20 E / IP20 E / IP20 Net weight [kg] 15,5 20,5 26 Volume [dB***]

2 gear/ 1 gear

57 / 57 59 / 57 61 / 59



Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Brand	Reventon
Parametry	Kind	with electric heater
Parametry	Power	6 W
Parametry	Product height	26.5 cm
Parametry	Product width	100 cm
Parametry	Product depth	19.5 cm
Parametry	Maximum mounting height	3 m
Parametry	Additional information	remote control included
Parametry	Product weight with unit packaging	16.5 kg
Parametry	Manufacturer code	AC100E1P
