Etikečių spausdintuvas Brother QL-820NWBc, LAN, Wi-Fi, Bluetooth

Trumpai apie prekę

Prekė: Etikečių spausdintuvas Brother QL-820NWBc, LAN, Wi-Fi, Bluetooth. Kategorija: Kiti spausdintuvai.

• Gamintojas: Brother
• Modelis: QL-820NWBc

Office two-color thermal printer with print width up to 62mm

• BLACK AND RED PRINTING*
• WIRED NETWORK LAN
• WIRELESS WI-FI
• BLUETOTH CONNECTIVITY
• PRINT WIDTH UP TO 62 MM
• BUILT-IN LABEL CUTTER
• PRINT RESOLUTION UP TO 300x600dpi
• BRAND NEW PRINTER
• OFFICIAL Poland DISTRIBUTION BROTHER
• 3 YEAR WARRANTY SERVICE (after registration on the brother website)

* on DK-22251 tapes

QL-820NWB is a professional-grade thermal label printer. It is characterized by a high print speed of 110 labels per minute or 176 mm per second in monochrome mode and 24 mm per second in two-tone mode.

The width of the media supported by it is from 12 to 62 mm, the maximum print length is 1 m, and its width is 58 mm.

The model prints on single paper and plastic tapes with lengths of 30,48 m or 15,24 m, as well as on ready-made cropped labels.

QL-820NWB prints in two colors: black and red, which allows you to highlight particularly important information on the produced labels, with two-color printing available using a special tape.

The printer allows for easy and quick marking of office materials: documents, binders, folders, CDs/DVDs, cables and plugs, identifiers and furniture. It will also be used in warehouses and logistics companies as a tool for marking packages, envelopes and cartons. QL-820NWB can also be used at retail outlets to print labels placed on goods, store shelves and displays. It is also a solution for food and restaurant manufacturers: it improves the production of markings with information on shelf life, allergens and delivery addresses.

QL-820NWB is equipped with a built-in guillotine, allowing you to quickly trim printed markings.

The device is equipped with an LCD display integrated with the control panel, offers a convenient ability to print labels from your own built-in memory, without having to connect to a computer.

It offers convenient operation, thanks to a number of supported interfaces.J The device is compatible with PC and Mac computers and mobile devices on Android and iOS platforms. It can work on Wi-Fi networks (it is compatible with AirPrint service) or connect via USB interface. The model also offers support for wired Ethernet and Bluetooth connectivity. The QL-820NWB is compatible with P-touch Editor software, enabling comprehensive label design using PC and Mac computers. The QL-810W also features built-in P-touch Editor Lite software, supporting the user in designing and editing labels and requiring no software or drivers to be installed. For users of this printer, Brother has provided a set of development tools for Windows, Android and iOS platforms, which allows you to create your own device-supported label printing applications.

The QL-820NWB label printer can be powered by an external power supply or by an optional battery.

It is sold in sets with a power supply and power cord, USB cable, a set of 100 cropped address labels and 62 mm by 5 meters two-color printing tape.

TECHNICAL SPECIFICATION

General

• Maximum label width (mm): 62
• Database transfer from computer: Yes
• Housing colour: black/white
• Transfer image from computer: Yes
• Memory capacity: 6 MB
• Memory locations: 255
• Technology: Direct thermal printing
• Transfer a template from your computer: Yes

General consumables

• Type: DK roll (cut labels / continuous tapes)

Connection

• AirPrint: Yes
• Bluetooth: Ver 2.1 EDR
• MFi: Yes
• Bluetooth profiles: SPP/OPP/BIP/HCRP
• USB interface: Ver 2.0 (full speed)
• Wired network interface: 10/100 BASE-TX
• Wireless network interface: IEEE 802.11 b/g/n

Dimensions and weight

• Dimensions: 125 x 234 x 145mm
• Weight: 1.16 kg

In the package

• Power supply: Yes
• Power supply cable for AC adapter: Yes
• Cassettes with tape: 29mm x 90mm - black print on white, standard address label; (100 labels) - 62mm black/red print on white, continuous tape (5 meters)
• USB cable: Yes
• User's Manual: Yes
• Warranty card: Yes
• Quick service manual: Yes

Network

• Wireless network security: WEP, WPA-PSK/WPA2-PSK （TKIP/AES), LEAP (CKIP), EAP-FAST (TKIP/AES), PEAP (TKIP/AES), EAP-TTLS (TKIP/AES), EAP-TLS (TKIP/AES)

Printing

• 1-dimensional barcode symbologies: CODE39, CODE128, UCC/EAN-128(GS1-128), ITF(I-2/5), CODABAR(NW-7), UPC-A, UPC-E, EAN13(JAN13), EAN8, GS1 DataBar(RSS)(GS1 DataBar Omnidirectional,GS1 DataBar Folded,GS1 DataBarred,GS
• 2-dimensional barcode symbologies: PDF417(Standard, Truncate, Micro), QR Code(Model 1, Model 2, Micro), Data Matrix (ECC200 Square, ECC200 Rectangular), MaxiCode, CODE93, POSTNET, UPC-E EXTENSION
• Printable in black and red: Yes
• Bitmap fonts: Helsinki, Brussels, Letter Gothic Bold, San Diego, Brougham
• Maximum label width: 62 mm
• Maximum printing width: 58 mm
• Contour/vector fonts: Helsinki, Brussels, Letter Gothic
• Resolution (dpi): 300 x 300, 300 x 600
• Standard printing speed: 110 labels per minute
• Standard printing speed: 176 mm per second

P-touch Editor label design software

• Database file compatibility: csv, Microsoft Access, Microsoft Excel
• Date and time stamp: Date and time
• Fonts: all installed fonts
• Frames: 126
• Label Orientations: Horizontal, Vertical
• Microsoft Office add-on (highlight->click->print): Excel, Outlook, Word
• Screenshot: Yes
• Sequential numbering: 1 - 9999 / A - Z / a - z
• Text Alignment: Center, Justify, Left, Right
• Font Styles: Bold, Horizontal Lines, Reversal, Italic, Normal, Shadow, Shadow Brightness, Surrounding
• Vertical printing: Yes

Solutions

• SDK (software expansion kit): Yes
