Garso kolonėlė ACV-5100BL 2.0

Trumpai apie prekę

Prekė: Garso kolonėlė ACV-5100BL 2.0. Kategorija: Garso juostos.

• Gamintojas: AMX
• Modelis: ACV-5100BL
• Spalva: black

The Acendo Vibe 5100 is a professionally designed soundbar specifically for web conferencing with an integrated camera.

Equipped with JBL sound, integrated connectivity that professional applications require. It is also its appearance, which perfectly harmonizes with the environment of a modern office or corporation.

With Acendo Vibe wide-angle cameras, integrated JBL speakers, far-field microphones and DSP algorithms, users can rest assured that everyone in the room is clearly visible and audible. In addition, because the camera and microphones are integrated into the same device, the possibility of echo reflection during the call has been eliminated.

HDMI, USB and Bluetooth connectivity supports BYOD environments as well as integration with Acendo Core, which provides an even more intuitive solution for indoor collaboration. CEC screen control turns the display on and off in response to triggering actions. Dedicated audio inputs and outputs can also be used to integrate Acendo Vibe with other room technologies, such as systems with enhanced listening.

Typical applications

With the tendency to open up to new work environments, small meeting spaces are becoming increasingly important. It is very important that these spaces are well adapted for quick, extremely intuitive cooperation, so as not to interrupt the daily rhythm of work. Bringing your own device into conference spaces that don’t have the right technologies means that the group is centered around the laptop, trying to hear and speak, using the audio and video of the laptop, which is really meant for the individual, not the group.

With a very reasonable entry price and low total cost of ownership, the Acendo Vibe is perfect for any workspace and can even be incorporated into small spaces that did not have a planned implementation of new technologies.

Functions

• JBL Sound - Hear everything that was said in the meeting with JBL speakers, microphones and DSP algorithms.

• Wide Angle Camera (110° FoV) - The wide angle camera works in such a way that anyone in the room can be seen, including people sitting close to the display. This makes the Acendo Vibe ideal even for small rooms where the table is near the screen.

• Elegant design - Modern office environments are designed to attract and retain the most talented employees through the use of elegant interior design and attractive finishing materials, such as e.g. appropriate fabrics. The Acendo Vibe is built with high-quality materials and is available in two colors designed to complement your home decor.

• CEC Display Control - Acendo Vibe will turn the display on and off in response to the corresponding triggers, making it even easier for users to start a meeting. For example, by connecting your laptop to the Acendo Vibe, the display will turn on and show the contents of your laptop. Since all this is done with CEC, there are no additional cables or programming required in connection with this simplification of installation.

• USB and Bluetooth Connectivity - Use Acendo Vibe in BYOD apps with your laptop or mobile phone, or use it with Acendo Core to create a complete, highly optimized meeting solution.

• Integrated mounting bracket – integrated wall mount allows installation by one person. This mount allows customers to connect and guide any wiring from the Acendo Vibe to the wall, then easily rotate the Acendo Vibe to the desired position.

General

• Dimensions: 132 mm x 590 mm x 105 mm

• Depth without spacers for wall mounting: 100 mm

• Height without camera: 76 mm

• Weight: 2,93 kg

• Mounting Options: Built-in hinged wall mount that allows installers to connect and manage cables when the Acendo Vibe is attached to the wall.

Installed rubber feet to place on the countertop. Rubber feet can be removed for wall mounting. However, it should be noted that in order to maintain optimal sound quality, rubber feet must be present when placed on the table.

Camera

• Resolution: up to 1920x1080p 30 fps. /s

• Camera sensor: 1/2,7" CMOS sensor

• Field of view (oblique): 110° wide angle

• Focus: 15 cm to infinity

• Camera rotation: can be rotated horizontally by 175° (± 5°) in both directions

• Camera tilt: down 5° / up 15°

• Encoding format: H.264

• Zoom: fixed

Connectors

• Analog stereo input 1/8" mini-stereo jack

• Analog stereo output 1/8" mini-stereo jack

• TOSLINK optical stereo input

• IEC C8 power supply

• 3-pin Phoenix RS-232 connector (connector included)

• USB Type-B port (USB 2.0)

• HDMI Type-A input jack

• HDMI Type-A output jack

• Occupation sensor: 3-pin Phoenix connector

USB

• USB 2.0: camera, microphones and speakers connecting to computers

using standard Plug and Play (PnP) UAC/UVC controllers.

USB connection used to configure Acendo Vibe with

PC/Mac applications.

HDMI

• Supported protocol: HDCP 1.4

• Support resolution: up to 4K60, CEC display control at output

• Audio support: uncompressed PCM stereo sound. Lack

support for multi-channel surround sound.

• Display Control CEC to control display on HDMI output

BLUETOOTH® 4.0

• Profiles supported: hands-free, advanced audio distribution profile

• Radio frequency range (RF): 2400 MHz – 2483,5 MHz

• RF output power: < 10 MW

Audio

• Supported: 10W stereo with channel amplifier, dual, far field microphone array, built-in acoustic echo cancellation (AEC) function

Remote

• Bluetooth® pairing for mobile devices

• Disconnection

• Mute the microphone

• Selection of source

• Volume up/down

• Volume mute
