HDMI į HDMI garso keitiklis su SPDIF, 3.5 mm jungtimi ir ARC

Trumpai apie prekę

Prekė: HDMI į HDMI garso keitiklis su SPDIF, 3.5 mm jungtimi ir ARC. Kategorija: Televizorių priedai.

• Gamintojas: Spacetronik
• Modelis: HDCEXTR06

SKU: HDCEXTR06

The most important features

✔ ARC via SPDIF – return audio from TV to receiver/soundbar with one stable connection

✔ 3 audio modes: PASS / 2CH / 5.1CH – matching to the source and sound system

✔ SPDIF Optical Output – Pure Digital Audio for Home Theater

✔ 3,5 mm Jack Output – stereo for active speakers or headphones (2CH mode)

✔ HDMI 2.0, 18Gbps – high bandwidth and compatibility with modern hardware

✔ Support 4K x 2K, 3D, 1080p@60Hz – no loss of image quality

✔ Color depth 24/30/36 bit – better quality in compatible installations

✔ USB-C power supply – easy and convenient power supply from TV, strip or charger

ARC – less cables, more convenience

If you want the sound from your TV to return to your receiver or soundbar without additional adapters, the SPH-AE06 is the perfect solution. You connect the TV via HDMI (ARC), and send the feedback sound optically SPDIF – stable and legible in configuration. The result is a neat TV set where everything works predictably: once you plug in and use it.

SPDIF Optical – pure digital audio for home theater

The SPDIF (Toslink) output is perfect for everyday use: it provides a stable connection and clear audio transmission to the soundbar or receiver. This is especially important in movies and games, where the readability of dialogues and synchronization of effects count. 5.1CH mode allows you to build a real home theater where HDMI directly to the receiver is not convenient.

4K HDMI 2.0 18Gbps – no compromises

The extractor should not be the “bottleneck” of the installation, which is why the SPH-AE06 supports HDMI 2.0 and 18Gbps bandwidth. Thanks to this, you transfer the image to the TV in high quality (4K x 2K, 3D, 1080p@60Hz), and distribute the audio to the selected output. Comfort is simple: the picture goes to the TV, the sound goes exactly where it is supposed to play.

USB-C power supply – simpler installation and aesthetics

USB-C power supply makes it easy to install and organize cables. You can power the device from the USB port of the TV, from the strip or charger. This is a practical solution in the TV cabinet and when mounted on the wall – less combination, more “plug & play”.

Technical specification

• Model: Spacetronik SPH-AE06
• Type: HDMI Audio Extractor with ARC
• Input: 1 × HDMI IN
• Outputs: 1 × HDMI OUT, 1 × SPDIF Optical, 1 × Jack 3.5 mm
• Audio Modes: PASS/2CH/5.1CH
• ARC: yes, works with SPDIF output
• Supported audio formats: 5.1CH mode supports Dolby TrueHD and DTS-HD Master Audio (for 5.1CH compatible source)
• Resolution: up to 4K × 2K, 1080p@60Hz, 3D support
• HDMI Standard: HDMI 2.0
• Max. bandwidth: 600 MHz
• Max. Transmission speed: 18 Gbps
• Max. Operating current: 350 mA
• Color Depth: 24 / 30 / 36 bit per channel
• Power Supply: USB-C

The set includes

• Extractor Spacetronik SPH-AE06
• SPDIF cable (optical)
• USB Network Adapter
• Instruction EN

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer code	HDCEXTR06
Parametry	Model	HDCEXTR06
Parametry	Brand	Spacetronik
Parametry	Kind	other
