Hidroforas su inverteriu, 80 l/min, 680 W, Smart Home

Trumpai apie prekę

Prekė: Hidroforas su inverteriu, 80 l/min, 680 W, Smart Home. Kategorija: Siurbliai ir hidroforai.

• Gamintojas: BG-INVEST
• Modelis: POMPA AUTOMATYCZNA ENERGOOSZCZEDN SMART HOME

Compact and energy-efficient SMART HOME device with built-in inverter, electronic control panel and pressure sensor stabilizes water pressure according to user settings.

Thanks to a modern control system and a permanent magnet (PM) motor, it consumes much less energy than traditional hydrophors. It can replace the classic hydrophore set or support the pressure in the urban network.

The system is equipped with a built-in inverter and pressure sensor, as well as full control electronics, which allows you to maintain a stable water pressure in the installation according to the user's preferences, within the limits of the pump's hydraulic parameters.

Minimized energy consumption – thanks to the use of a modern permanent magnet motor (PM) and an advanced control system, the device operates with high efficiency and consumes much less electricity than traditional hydrophors.

Gradual starting and stopping of the engine eliminates the risk of sudden pressure spikes and hydraulic impacts in the pipes.

Automatic activation of the device after the start of water intake (e.g. unscrewing the tap) and its automatic shutdown after use (turning off the tap).

Quiet operation and compact design allow installation even near living quarters without disturbing the comfort of users.

The system is equipped with protection against:

• Dry work
• Excessive increase in water temperature
• Engine overload
• Overheating of the system
• Incorrect electrical voltage (too high or low)
• Risk of freezing water in the pump housing

• Max. Efficiency: 80 l/min
• Max. lifting: 43 m
• Max. Engine power: 680 W
• Max. Pressure: 4,3 bar
• Max. suction depth: 8 m
• Supply Voltage: 230 V
• Stub Size: 1" x 1"
• Water temperature: 0÷90⁰C
• Ambient temperature (operation): 0÷40⁰C
• Engine speed: 5400 rpm
• Cable length: 1,2m

• Copper winding
• Motor with permanent magnets
• Shaft made of stainless steel
• Impeller made of techno polymer

• DNA -25
• DNM - 25
• a - 240
• b - 300
• c - 85
• d - 100
• e - 190
• f -75
• g - 13

This smart pump control panel with inverter is a modern and intuitive management center that gives you complete control over your pump's operation. Thanks to advanced control technology, you can easily monitor and adjust the pump's operating parameters, ensuring optimal performance and energy efficiency.

A key function of the panel is the ability to precisely adjust the pump's power to the current water demand. The inverter dynamically regulates the motor speed, which allows for smooth operation, reduces energy consumption, and limits the wear and tear on the pump's mechanical components, extending its lifespan.

The control panel is equipped with a clear display that presents key information about the device's status, such as pressure, power consumption, and any service alerts. The intuitive user interface allows for easy programming of parameters and quick response to changing operating conditions.

Specifications
