IP kupolinė kamera BCS-L-EIP18FCR3L3-AI, 8 Mpx, NightColor, su mikrofonu, BCS Line

Trumpai apie prekę

Prekė: IP kupolinė kamera BCS-L-EIP18FCR3L3-AI, 8 Mpx, NightColor, su mikrofonu, BCS Line. Kategorija: Fotoaparatai.

• Gamintojas: BCS
• Modelis: BCS-L-EIP18FCR3L3-AI

BCS-L-EIP18FCR3L3-AI – high 4K resolution and NightColor technology

The BCS-L-EIP18FCR3L3-AI dome camera from BCS is the flagship device in the BCS LINE series providing 8 Mpx (4K) resolution images. The use of a modern 1/2.7'' CMOS sensor and NightColor technology ensures the recording of detailed recordings in a full color palette even at extremely low lighting levels. The fixed-focal lens of 2.8 mm guarantees a very wide horizontal viewing angle of 110 degrees. This allows for precise monitoring of vast areas while maintaining the highest sharpness of details necessary to identify people and events.

Intelligent SMD analytics and hybrid lighting

This model has a built-in SMD artificial intelligence algorithm for precise recognition of the human figure. The system effectively eliminates false alarms caused by the movement of vegetation, precipitation or animals. Hybrid illuminator combining IR LEDs and white light with a range of up to 30 meters guarantees optimal visibility at night. The built-in high-quality microphone allows for simultaneous recording of video and sound. This increases the evidentiary potential of the recorded video.

Characteristics

• Transducer: 1/2.7'' 8Mpx CMOS Progressive Scan,
• Resolution: 8 Mpx 4K (3840×2160),
• Fixed focal length lens: 2.8 mm,
• Viewing angle: H: 110°, V: 58°, D: 132°,
• NightColor Technology: Color image in night conditions,
• Hybrid illuminator: IR range up to 30m and WhiteLight up to 30m,
• Intelligent SMD detection: Human body recognition,
• Audio: Built-in high-quality microphone,
• Video compression: H.265+ / H.265 / H.264+ / H.264,
• Image Functions: DWDR, BLC, HLC, 3D DNR, ROI,
• Day/Night: ICR Mechanical Infrared Filter,
• Corridor mode: 90°/270° rotation of the image,
• Remote support: Web Service, CMS BCS Manager, Mobile App,
• Protection class: IP67 (full resistance to dust and water),
• Power supply: 12V DC/PoE (802.3af),
• Power Consumption: Maximum 5.8W,
• Operating temperature range: -40°C to +60°C,
• Security: HTTPS, Trusted boot, Trusted upgrade.

Technical data

• Device name: BCS-L-EIP18FCR3L3-AI
• Product line: BCS LINE
• Camera type: Dome
• Resolution: 8 Mpx
• Converter: 1/2.7'' CMOS
• Scanning system: Progressive Scan
• Pixels: 3840(H)×2160(V)
• RAM: 256MB
• ROM: 128MB
• Lens: fixed
• Focal length: 2.8 mm
• Aperture: F1.6
• Focus: Fixed
• Iris: Permanent
• Digital Zoo: 16×
• Angle of view: H: 110° V: 58° D: 132°
• DORI: Detect 84.8m / Observe 33.9m / Recognize 17m / Identify 8.5m
• Camera sensitivity: 0.008Lux(Color,F1.6,30IRE) 0.0008Lux(F1.6,B/W,30IRE) 0Lux(IR)
• S/N ratio: 56dB
• White Balance: (AWB) Auto / Manual
• WDR: DWDR
• Background compensation: BLC / HLC / DWDR
• Snapshot: Auto / manual 1/3~1/100000s
• Gain control: (AGC) Auto / manual
• Noise reduction: 3D DNR
• RoI: Region of Interest
• Image rotation: Mirror, Flip 0°/90°/180°/270°
• Number of streams: 2
• Resolutions: 8M, 6M, 5M, 4M, 3M, 1080p, 1.3M, 720p, D1, VGA, CIF
• Main stream: 3840×2160(1~20fps) 2688×1520(1~25/30fps)
• Second stream: 704×576(1~25fps) 704×480(1~30fps)
• Bitrate: H.264: 32 kbps~8192kbps H.265: 12 kbps~8192kbps
• Video compression: H.265+ / H.265 / H.264+ / H.264 / MJPEG
• Day/night: ICR mechanical infrared filter
• Type of illuminator: IR LED + WhiteLight
• IR range: 30m
• WhiteLight range: 30m
• NightColor: Yes
• Microphone: Yes
• Audio compression: G.711A / G.711Mu / G.726 / PCM
• Storage: FTP
• Support: Web Service, CMS BCS Manager, Mobile App
• Motion detection: 4
• Privacy masks: 4
• Network: RJ-45 10/100 Mbps
• Compatibility: ONVIF(S/T)
• Protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
• Security: Digest, WSEZ, Account lockout, Security logs, HTTPS, Trusted boot
• Power Type: 12V DC / PoE(802.3af)
• Power consumption: max 5.8W
• Housing color: White
• IP protection class: IP67
• Working conditions: -40°C~+60°C max 95% RH
• Dimensions: Ø94×85.6mm
• Weight: 0.35 kg
• Ai - Built-in intelligent functions: Image recognition and analysis algorithms
• Ai - SMD: Intelligent motion detection with human recognition

Comprehensive use of the BCS-L-EIP18FCR3L3-AI camera

The BCS-L-EIP18FCR3L3-AI is the flagship IP solution of the BCS LINE series, which, thanks to its ultra-high resolution of 8 Mpx (4K) and NightColor technology, redefines the standards of modern monitoring. The compact housing with a diameter of 94 mm allows for discreet installation while maintaining the highest parameters of identification of people and events in all lighting conditions.

Main areas of use

• 4K monitoring for business: Precise identification of details, faces and denominations in banks and exchange offices,
• Residence security: Intelligent perimeter protection with human detection notifications (SMD),
• Trading and boutiques: Recording events in full NightColor even after the lights are completely turned off,
• Operating stations: Video surveillance with simultaneous audio recording thanks to the built-in microphone,
• Logistics and warehouses: Monitoring processes over long distances using a wide 110° angle,
• External installations: Protection of parking lots and construction sites in difficult conditions (IP67 protection class).

Functional and assembly advantages:

• Ultra HD 8 Mpx: Huge pixel density for effective digital close-ups,
• Hybrid illuminator: Automatically illuminate the scene with white light when an intruder is detected,
• PoE power supply: Simplified wiring structure through data and energy transmission with one twisted pair,
• Corridor mode: Optimization of the frame for observing long staircases and passages,
• Small dimensions: Possibility of aesthetic installation in suspended ceilings and facades.
