Išmanusis namų valdymo pultas Tuya 10", Zigbee, Bluetooth

Trumpai apie prekę

Prekė: Išmanusis namų valdymo pultas Tuya 10", Zigbee, Bluetooth. Kategorija: Centriniai blokai.

• Gamintojas: Automat-on
• Modelis: AUT001171

The Tuya Smart intelligent control panel with a 10" touch screen is a modern home automation management center in the Tuya ecosystem. The device combines the functions of a wall panel, ZigBee and Bluetooth multigateway, and WiFi control, allowing you to operate multiple devices from one place. It's a convenient solution for a home, apartment or modern office where quick access to lighting, scenes, automation and other smart home elements is important.

Touch screen and quick function operation

The panel is equipped with a large IPS TFT LCD screen with a resolution of 1920 × 1200 , which ensures very good readability, natural colors and smooth operation . The matrix displays 16.7 million colors , and the 60 Hz refresh rate makes navigating the interface comfortable and responsive. The screen can be personalized by selecting ready-made themes, widget layouts, and screensaver schedules, making it easy to match the panel to your interior style and habits.

Technical parameters

• Screen: 10-inch multi-touch screen / 1920 resolution × 1200
• Memory: 2 GB RAM / 8 GB ROM
• Camera: 5 million pixels / privacy cover
• Audio: 2 × speaker / 2 × microphone
• Wireless protocols: Wi-Fi / Zigbee 3.0 / Bluetooth 5.0 BLE / BLE mesh
• Sensors: TOF proximity sensor / ambient light sensor / temperature and humidity sensor
• Operating modes: touch screen / physical buttons / voice control / application
• Interface: USB Type-C (debugging only, input: DC 12 V, max. 1,0 A)
• Working temperature: 0 – 40°C
• Working humidity: 5%–90% RH, non-condensing
• Input power supply: 100 – 240 V~, 50/60 Hz

Control the whole house from one panel

The device allows you to control a wide range of products that work with Tuya Smart. From the panel, you can operate, among others, lighting, dimmers, LED controllers, thermostats, light switches, curtain robots, cameras and TAP TO RUN scenes created in the application. The panel also gives a preview of ZigBee devices added to the system, and after the update allows to control even more elements of the smart home. Additional convenience is provided by programmable physical buttons, to which you can assign your favorite functions, scenes or automations.

Multimedia features and additional capabilities

A big advantage of the panel are also multimedia and communication functions. The device supports Bluetooth, so you can connect headphones, speakers or other audio accessories, a also enjoy music playback and intuitive sound control at home. The built-in microphone supports cooperation with IP cameras and videophones, a 5 MP camera and intercom function expand the possibilities of everyday communication and access control. The current time and weather downloaded from the Internet may also be displayed on the screen.

Smart home in one app

The panel works with the Tuya Smart app and allows you to manage devices throughout your home from one place. It allows you to create scenes, schedules and automations depending on the weather, location, sensors or selected events in the system. The built-in Amazon Alexa voice assistant allows you to control your devices without having to buy a separate speaker, and the proximity sensor automatically wakes up the screen when motion is detected. This is an extensive and at the same time easy-to-use solution for people who want to have full control over their smart home in one panel.

Expanded integration capabilities

A big advantage of the panel is the built-in multi-gate ZigBee and Bluetooth, thanks to which it can act as a central control point for Tuya devices throughout the house. On the plus side, there is also support for Amazon Alexa, the ability to run TAP TO RUN scenes, personalize the home screen and quick access to selected devices through widgets and programmable buttons. Additional advantage are intercom functions, cooperation with cameras and video intercoms and a proximity sensor that automatically wakes up the screen when motion is detected.

Specifications
