Jutiklis MikroTik TG-LR82, LoRaWAN, EU868, 868MHz/2.4GHz, IP67

Trumpai apie prekę

Prekė: Jutiklis MikroTik TG-LR82, LoRaWAN, EU868, 868MHz/2.4GHz, IP67. Kategorija: Jutikliai.

• Gamintojas: Mikrotik
• Modelis: TG-LR82

LoRaWAN Sensor for 868 MHz and 2.4 GHz Frequencies, with Built-in Temperature, Humidity, Motion, and Event Sensors, IP67 Outdoor Enclosure, and Mounting Bracket, includes LiMnO2 Battery (EU, India, etc.)

• Temperature monitoring
• Detection of humidity, motion and tilt
• Support reed switches for doors, lids and cabinets
• Customizable profiles and rules
• Battery life up to 5 years
• Event-based telemetry
• Housing with IP67 degree of protection
• Designed for long-term use
• Support for 868 MHz and 2,4 GHz frequencies
• Includes mounting bracket with pronunciation. 77 x 46 x 6,5 mm

MikroTik TG-LR82 to sensor, tag, LoRaWAN supporting frequency 868 MHz and 2,4 GHz, equipped with built-in temperature, humidity, motion and event sensors, external housing IP67 and mounting bracket, with LiMnO₂ battery (European Union, India, etc.).

MikroTik TG-LR82 is a configurable LoRaWAN sensor: a flexible and cost-effective tool for collecting data and making informed operational decisions. Monitor temperature, humidity, traffic and events with a customizable LoRaWAN sensor designed for demanding IoT deployments.

The TG-LR82 combines multiple sensors, intelligent event rules and flexible reporting profiles in one compact device – making it easier to monitor your surroundings, equipment and logistics over long distances. The device has been designed to work seamlessly with MikroTik LR8 gates and modern monitoring platforms.

Versatile sensor with local data processing

MikroTik TG-LR82 combines ambient monitoring and motion detection functions with built-in data processing.

With its high temperature accuracy, the TG-LR82 is perfect for monitoring goods and environments sensitive to temperature changes. The device can generate average temperature and humidity values or histograms before transmitting telemetry data. This reduces network load while retaining valuable information about environmental conditions.

Automation: When conditions change, the sensor responds

The TG-LR82 sensor supports multiple configuration profiles and event-driven rules, allowing the device to automatically adapt to changing conditions. This enables the implementation of advanced monitoring scenarios without the need for complicated back-end logic.

The MikroTik TG-LR82 sensor enables flexible configuration via LoRaWAN downlinks. Configuration data can be generated using a dedicated tool or integrated with platforms such as The Things Network (TTN)

Flexible LoRa Networking in the 2.4 GHz Band!

The MikroTik TG-LR82 also supports 2.4 GHz LoRa technology, enabling deployments without regional frequency restrictions. Unlike sub-1 GHz LoRa bands that vary by region, 2.4 GHz LoRa can be used globally without frequency switching.

Typical range can be around 1.5 km, depending on the network gateway antenna and environmental conditions. This makes it a practical solution for mobile assets like container ships or international logistics systems.

A similar logic can be applied to other monitoring scenarios: temperature or humidity thresholds, impact or free-fall detection, orientation or tilt monitoring, equipment and asset activity tracking, etc. The integrated reed switch allows for detecting door or lid openings and enables simple interaction with the device using a magnet. From cold chains to warehouses, from logistics to environmental research, the TG-LR82 is suitable for many applications!

Works with your monitoring system

The sensor data of the TG-LR82 can be visualized and analyzed using modern monitoring platforms such as Grafana. With support for containers in the MikroTik RouterOS system, Grafana dashboards can be quickly deployed, enabling real-time telemetry data visualization and historical analysis.

Examples of telemetry information include:

• Temperature and humidity trends
• Orientation and states of activity
• Histograms of environmental parameters
• Battery status and signal strength

Designed for long-range IoT networks

MikroTik TG-LR82 smoothly integrates with LoRaWAN MikroTik LR8 gates, including KNOT LR8G kit, wAP LR8G kit and wAP LR2 kit. Combined, they provide long-range connectivity for sensor installations in buildings, industrial areas or outdoor environments.

• LoR receiver: LR1120
• LoR band: 868MHz / 2.4GHz
• Supported LoRaWAN protocol: LoRaWAN 1.0.4 Class A, B
• RF transmitting power: 868MHz: 10.5dBm, 2.4GHz: 13dBm
• RF reception sensitivity: 868MHz: -141dBm (BWL = 125kHz, SF = 12), 2.4GHz: -130dBm (BWL = 812kHz, SF = 12)
• Antenna gain: 868MHz: -4dBi, 2.4GHz: 2dBi
• Additional LoRaWAN features: ADR (Adaptive Data Rate)
• LoRa region identifier: EU868
• Sensor type: Temperature, humidity, accelerometer
• Temperature sensor: TMP116N sensor with NIST tracking capability
• Temperature sensor accuracy: ±0,2°C typically (±0,3°C max. ) for the range from -25°C to +85°C
• Humidity sensor: 0% -100% RH
• Dimensions: 76 x 45 x 19 mm
• Battery: 1100 mAh LiMnO₂, non-replaceable
• Working temperature: from -10°C to +70°C

The device is ready to work with "The Things Network" - a famous open source infrastructure that provides free LoRaWAN coverage and has multiple applications for every need. The Things Network helps you get started with the Internet of Things in one day. Cattle tracking, smart irrigation, thermostats, smart measurements, etc. - the possibilities are endless. Setup is so simple that anyone can get started really quickly. With the SLA service backed by The Things Industries, deploying secure and scalable LoRaWAN solutions has never been easier. There are global communities of developers, companies and enthusiasts who will always help answer questions and share ideas about LoRaWAN. Just join "The Things Network" to save time and energy with smart solutions!
