Kraujospūdžio pulsoksimetras GIMA OXY-1 ID-1089

Trumpai apie prekę

Prekė: Kraujospūdžio pulsoksimetras GIMA OXY-1 ID-1089. Kategorija: Pulso ir deguonies matuokliai.

• Gamintojas: Gima
• Modelis: OXY-1
• Spalva: blue

PULSOXIMETER GIMA OXY-1 ID-1089

The CMS50DL from the leading medical equipment manufacturer CONTEC MEDICAL SYSTEMS is one of the most recognized and classic pulse oximeters on the market.

Proven design, high quality and precise measurement are the factors of the huge popularity of this model.

Its exceptional ease of use makes it a universal device designed for a wide range of users.

Medical device registered with the Office for Registration of Medicinal Products, Medical Devices and Biocidal Products.

CONTEC CMS50DL is a medical device with CE Certificate (Certificate of Conformity) issued by an authorized EU notified body: TÜV SÜD PRODUCT SERVICE GMBH RIDLERSTR 65, D-80339 MÜNCHEN, GERMANY

Basic features:

• Integrated with SpO2 probe and process display module.
• Single color LED screen.
• Small size, light weight and comfortable to wear.
• Product operation is simple, low power consumption.
• Display SpO2 and heart rate.
• The low voltage indicator appears before malfunction caused by low voltage.
• Automatic shutdown within 5 seconds, from removing the finger
• Power supply: 1,5V alkaline batteries (AAA size) × 2; two batteries can work continuously for 24 hours, the theoretical number is 50 hours. Measurement parameters:

  0% ～ 100% (resolution is 1%)

  Accuracy:

  70% ～ 100% ： ± 2%,Below 70% unspecified

  Measurement range PR

  30 beats per minute - 250 beats per minute,(resolution is 1 beat per minute)

  Accuracy:

  ± 2 beats per minute

  or ± 2% (choose larger)

  Measurement performance in low fill conditions:

  SpO2 and heart rate can be correctly displayed when the pulse fill factor is 0,4% SpO2 error is ± 4%,heart rate error is ± 2 bpm or ± 2% (choose larger)

  Resistance to surrounding light:

  The deviation between the value measured under artificial light or natural light conditions in the room and the darkroom is less than ± 1%.

  Other technical data:

• Supplier code: GIMA OXY-1
• Brand: GIMA
• Package Quantity: 1 piece
• Dimensions: 57(L) 31(W) 32(H) mm
• Device weight: about 50 g (incl. batteries)
• Saturation measurement range (SpO2): 0% 100% (resolution is 1%)
• Pulse measurement range: 30 beats per minute - 250 beats per minute, (resolution is 1 beats per minute)
• Power supply: DC 2,6 V - 3,6V
• Power Supply: Batteries (Packaging)
• Tax rate: VAT 8%
• Measurement range SpO2:

Specifications
