Magnetinis gręžtuvas STAKO, 1480 W, 40 mm, 10 kg

Trumpai apie prekę

Prekė: Magnetinis gręžtuvas STAKO, 1480 W, 40 mm, 10 kg. Kategorija: Gręžimo staklės.

• Gamintojas: Stako
• Modelis: ST-N4000
• Galia: over 851 W

* Equipped with:

1. WELDON 19 mm ¾" drill chuck with internal cooling system (for trepanation / core cutters)

2. Borkop B16 / 3 – 16 mm drill chuck (for cylindrical drill bits)

TECHNICAL DATA:

• Engine power: 1480 Watt
• Power supply: 230 V / 50 - 60 Hz
• Soft start (soft-start): YES
• Tool holder: Weldon 19mm + Borkop B16 / 3 - 16 mm
• Max. Ø drilling (full/roller drill): 16 mm
• Max. Ø drilling (tube): 40 mm
• Speed control: YES (100 - 690 rpm /min.)
• Height (max. /min.): 570 mm / 340 mm
• Working stroke: 240 mm
• Magnetic force: 15500 N (1550 kg)
• Magnetic foot dimensions: 175 / 85 mm
• Weight: 10 kg

THE MAIN ADVANTAGES:

• ✅ High quality workmanship
• ✅ Simple operation
• ✅ Gentle start-up and smooth speed control
• ✅ Wide range of drilled holes
• ✅ Compact size, compact and lightweight design (10 kg)

Thanks to its small size, the drill is great for use in hard-to-reach places.

The compact and lightweight design guarantees easy transport and convenient positioning of the machine.

Gentle start-up and smooth speed control in the range of up to 690 revolutions per minute, does not burden the engine, which extends its service life and is useful when working with different drill diameters.

Our magnetic drill is a guarantee of increasing the efficiency and precision of the holes, avoiding mistakes and damage to the material that can occur during classic manual drilling. Moreover, it makes the drilling process much faster, which translates into saving time and resources.

This type of equipment is an alternative to table machines, is characterized by much lower weight, greater mobility and comfort of work, while maintaining sufficiently high technical parameters, including engine power.

Control panel

Intuitive and ergonomic control panel ensures comfort and safety at work. Equipped with:

• Electromagnetic on/off button – allows quick and safe attachment of the drill to the metal surface.
• Separate spindle drive switch – allows you to start the motor only after activating the electromagnet, which prevents accidental start-up.

The panel is designed for easy operation even with work gloves and provides quick access to all the most important functions of the device.

In addition, on the top of the drill housing there is:

• Rotary speed control knob – allows precise adjustment of rotations to the type of material and diameter of the drill, improving the quality and efficiency of drilling.

The double coil magnet, which generates a magnetic field with a high attraction force of 15500 N (1550 kg), enables safe horizontal, vertical and above-the-head operation, ensures stability and confidence in attaching the drill to the metal surface and enables precise and efficient drilling of holes.

• 1 x Magnetic drilling machine STAKO ST-N4000
• 1 x Weldon 19 mm 3/4" Drill Chuck
• 1 x Borkop 3 – 16 mm drill chuck
• 1 x Coolant tank with cable
• 1 x Drill Chuck Attachment Pin
• 1 x Drill Chuck Crimping Wrench
• 3 x Feed handle
• 3 x Allen Wrench
• 1 x Seat Belt
• 2 x Motor Brushes
• 1 x Fuse
• 1 x Manual
• 1 x Carrying case

Specifications
