Aprašymas
Trumpai apie prekę
Prekė: Multimedijos centras FIAT 500 2007–2015, 9" Android 15, 4+64 GB, CarPlay, WiFi, GPS, AHD kamera. Kategorija: Radijo grotuvai.
- Gamintojas: no brand
- Modelis: RAH3125
TECHNICAL PARAMETERS
- Operating system: Android 15
- Processor: Quad-Core ARM Cortex-A53
- RAM: 4 GB
- Internal memory: 64 GB
- Display: 9" LCD with capacitive touch panel
- Screen resolution: 1280 × 800
- Wi-Fi: 2,4 GHz
- Bluetooth: hands-free calling and music playback
- Apple CarPlay: wired and wireless
- Android Auto: wired and wireless
- Mirror Link: supported
- Navigation: GPS
- Radio: FM
- Sound Corrector: EQ
- Split Screen: supported
- Picture-in-Picture: supported
- Audio formats: MP3, FLAC, APE, WMA, WAV, AAC, M4A, AMR, Opus, MID, OGG
- Video formats: AVI, ASF, MP4, MOV, MPG, MPEG-1/2/4, VOB, MKV, FLV, TS, WMV, RMVB, 3GP
- System languages: English, Polish, Slovak, Czech, Hungarian, German, French, Italian, Spanish, Portuguese, Russian, Turkish and others
- Control from the steering wheel: operated by CANBUS
- Reversing camera input: AHD 1080P/720P and CVBS
- USB: 2 USB connectors
- Audio outputs: RCA and SUB
- Audio input: AUX
- External microphone: supported
- Amplifier: YD7388
- Working voltage: 9 – 16 V
COMPATIBILITY
- Fiat 500: 2007 – 2015
The radio is designed for the first generation Fiat 500, whose center console and factory radio correspond to the examples shown in the photos of the offer.
Before buying, compare the color and shape of the panel, the appearance of the center console, the factory radio and the car connectors with the product photos.
APPLE CARPLAY AND ANDROID AUTO
The radio supports Apple CarPlay and Android Auto. After connecting a compatible phone, you can use directly on the screen of the device with:
- maps and navigation
- music and podcasts
- telephone calls
- news
- compatible voice assistant
The availability of applications and individual functions depends on the phone model, its system and the software used.
ANDROID 15, 9" SCREEN AND 4+64GB MEMORY
- The capacitive 9" touchscreen with a resolution of 1280 × 800 provides a clear image and convenient operation of navigation, music, calls and applications.
- The quad-core ARM Cortex-A53 processor and 4 GB of RAM enable efficient support for the basic functions of Android 15.
- 64 GB internal memory provides space for applications, offline maps, music and other media files. This is a practical configuration designed for everyday use in the car.
WI-FI AND BLUETOOTH
Built-in Wi-Fi allows you to connect the radio to your phone's hotspot or other available wireless network. Once you have access to the internet, you can use compatible apps, online navigation and multimedia.
Bluetooth allows you to:
- conducting telephone conversations
- wireless music playback
- synchronization of the telephone book
- Use of compatible phone features
ONLINE AND OFFLINE GPS NAVIGATION AND SPLIT SCREEN
- The built-in GPS module allows you to use popular navigation applications. After downloading the appropriate maps in advance, the device can also conduct offline navigation, without a permanent Internet connection.
- The included GPS antenna helps to achieve stable satellite signal reception.
- The divided screen feature allows two compatible applications to be displayed simultaneously, such as navigation and a music player.
REVERSING CAMERA AHD, CANBUS AND STEERING WHEEL CONTROL
- The set includes an AHD reversing camera. The radio supports CVBS and AHD signals at 720P or 1080P resolution.
- When properly connected, the camera image is automatically displayed when the reverse gear is turned on. The AHD camera provides a more detailed image than a standard CVBS camera, making it easier to observe the space behind the car while parking.
- The included CANBUS module allows the radio to communicate with the installation of a compatible Fiat 500 and support buttons on the steering wheel. The availability of individual functions depends on the equipment of the car.
RADIO FM/RDS, EQUALIZER EQ AND MULTIMEDIA
The built-in tuner supports FM band and RDS function. RDS can display information transmitted by compatible stations, including the station name and current broadcast data.
The sound equalizer allows you to adjust the sound of the music to your preferences.
The radio also allows you to:
- Playing music via Bluetooth
- Playing files from a USB stick
- connection of the sound source via AUX
- Use of four audio output channels
- Connecting a compatible subwoofer
- Playing popular audio and video formats
Two USB connectors allow you to connect a portable memory, phone or compatible accessories.
CONTENTS OF THE SET
- Android 15 radio with 9" screen
- Dedicated mounting panel for Fiat 500
- AHD reversing camera
- CANBUS module
- dedicated main power harness
- reversing camera input cable
- RCA cable
- 4-pin USB cable with USB adapter
- 6-pin USB cable
- external microphone
- GPS antenna
- dismantling tool
- installation instructions
IMPORTANT INFORMATION BEFORE PURCHASE
The radio is designed for the Fiata 500 from 2007 to 2015, whose center console, factory radio and connectors correspond to the examples shown in the photos of the offer.
Before buying, you should carefully compare:
- Console panel shape and color
- appearance of the front part of the factory radio
- dimensions of the mounting place
- type of connectors behind the radio
The CANBUS module is factory connected to a dedicated beam. Do not disconnect the CANBUS connector as this may cause some functions to become unavailable.
The factory car microphone is not supported. Use the external microphone included in the kit.
In this model, Wi-Fi and Bluetooth should not be used simultaneously. If you have connection problems, disable one of these features.
Installation should be carried out with the power off and the battery disconnected. The availability of steering wheel control and information provided by CANBUS depends on the factory equipment of the car.
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With invoice (excluding VAT) |
| Parametry | Brand | no brand |
| Parametry | Kind | accessory |
| Parametry | Model | RAH3125 |
| Parametry | Product weight | 1.8 kg |
| Parametry | Amplifier power | 4x45 W |
| Parametry | Media played | USB |
| Parametry | Screen diagonal | 9" |
| Parametry | Installation | 2-DIN |
| Parametry | EAN (GTIN) | 7841971127548 |
| Parametry | Manufacturer code | RAH3125 |
| Parametry | Packaging status | original |
| Parametry | Supported file formats | .aac,.ape,.flac,.mp3,.wav,.wma |
| Parametry | Radio | RDS information,FM band |
| Parametry | Functions | touchscreen,sound equalizer,playing music from iPhone/iPod |
| Parametry | Ports | AUX,RCA pre-out (preamplifier),RCA sub-out (subwoofer),USB |
| Parametry | Communications | Bluetooth,GPS,Wi-Fi |
