Naudotojo vadovas EPSON EcoTank L8160

Trumpai apie prekę

Prekė: Naudotojo vadovas EPSON EcoTank L8160. Kategorija: Rašaliniai ir lazeriniai spausdintuvai.

• Gamintojas: Epson
• Modelis: EcoTank L8160

EPSON EcoTank L8160 user manual

P/N : C11CJ20402

Technology

Printing method

6-Color Inkjet Printer

Nozzle configuration

360 black nozzles, 180 nozzles per colour

Minimum droplet size

1,9 pl, With variable size drop technology

Ink technology

Black pigment ink and colored water inks

Printing resolution

5.760 x 1.440 DPI

Performance

Home, Pictures

Multifunctional

Printing, Scanning, Copying

Printing

Number of colours

6 colour

Print speed ISO/IEC 24734

16 Str. /min. Monochrome, 12 Str. /min. Colour, 25 seconds per photo 10 x 15 cm

Print speed

32 Str. /min. Monochrome (Plain Paper), 32 Str. /min. Colour (plain paper), 15 seconds per photo 10 x 15 cm (glossy Premium Glossy Photo Paper)

Double-sided printing speed ISO/IEC

6 p. A4/min Monochrome, 5 p. A4/min Colour

Recommended duty cycle

800 Pages per month

Colors

Black [Pigment], Photographic Black [Dye], Cyan [Dye], Yellow [Dye], Magenta [Dye], Grey [Dye]

Printing with

PC, MAC, USB, Mobile Device (WiFi Direct), Mobile Device (Wireless)

Scanning

Scanning resolution

1.200 DPI x 4.800 DPI (Horizontal x Vertical)

Editing formats

BMP, JPEG, TIFF, Scan to multi-TIFF, PDF, Scan to PDF, PNG

Scanner type

Image contact sensor (CIS)

Support for paper/carriers

Number of paper compartments

3

Paper formats

A4 (21.0x29,7 cm), A5 (14,8x21,0 cm), A6 (10,5x14,8 cm), B5, B6, C6 (envelope), DL (envelope), No. 10 (envelope), Letter, 10 x 15 cm, 13 x 18 cm, 100 x 148 mm, User

Double-sided

Yes (A4, plain paper)

Printing margin

0 mm upper, 0 mm right, 0 mm lower, 0 mm left (If margin is defined. Otherwise, 3 mm upper, left, right, lower).

Capacity of receiving tray

50 Sheets

Capacity of paper tray

100 Sheets As standard, 20 Photo Sheets

Rear paper path (special media)

Yes

Thickness

Single Sheet1,3 mm

Appropriate paper weight

64 - 300g/m²

Print media processing

Automatic double-sided printing (A4, plain paper), Marginless printing, CD/DVD printing, Artistic, Rear feeder for special media, Thick substrate support

General information

Energy consumption

17 W (autonomous copying, standard ISO/IEC 24712), 0,8 W (sleep mode), 7,5 W Ready, 0,3 W (off), TEC 0,16 kWh/week

Power supply voltage

AC 220 V - 240 V, 50 Hz - 60 Hz

Product dimensions

403 x 369 x 162 mm (Width x Depth x Height)

Product weight

8,4 kg

Noise level

5 B (A) according to ISO 7779 print pattern on Epson Premium Glossy Photo Paper / Photo RPM mode - 37 dB (A) according to ISO 9226

Compatible operating systems

Mac OS X 10.6.8 or later, Windows 10 (32/64 bit), Windows 7 (32/64 bit), Windows 8 (32/64 bit), Windows 8.1 (32/64 bit), Windows Vista (32-bit/64-bit), Windows XP Professional x64 Edition SP2 or later, Windows XP SP3 or later (32-bit), Windows Server 2003 SP2 or later

Included software

Epson Photo+, Epson ScanSmart, EpsonNet Config

Connections

USB, Ethernet, Wi-Fi Direct, USB Host, IEEE 802.11a/b/g/n/ac Wireless LAN, SD Card Slot

Printing services from mobile devices and in the cloud

Apple AirPrint, Mopria Print Service, Epson Smart Panel App, Epson Connect (Email Print, Remote Print Driver), Epson Connect (Email Print, Scan-to-Cloud)

Other functions

LCD display

Type: Color, Touch screen, Diagonal:10,9 cm

Memory cards

SD, SDHC, SDXC, MicroSD*, MicroSDHC*, MicroSDXC*, MiniSD*, Mini SDXC*, MiniSDHC* (* Adapter required, not included)

Functions

Touch Screen, PictBridge, Direct Printing, Printing Directly from USB

Performance of the included container

Black ink yield

1.800 photos

Color ink yield

1.800 photos

Product safety

Product safety warnings

Contains 1,2-benzoisothiazole-3(2H)-one. It can cause an allergic reaction.

Contains 2,4,7,9-tetramethyldec-5-yne-4,7-diol. It can cause an allergic reaction.

Always follow the information on the product label.

Specifications

Group	Name	Value
Parametry	Condition	new
Parametry	Invoice	With VAT invoice
Parametry	Manufacturer code	C11CJ20402
Parametry	Brand	Epson
Parametry	Model	EcoTank L8160
Parametry	Type	multifunction printer
Parametry	EAN (GTIN)	8715946676340
Parametry	Packaging status	original
Parametry	Certificates of conformity	CE
Parametry	Product weight with unit packaging	8.4 kg
Parametry	Device color	white
Parametry	Product width	40.3 cm
Parametry	Product depth	36.9 cm
Parametry	Product height	16.2 cm
Parametry	Printing technology	inkjet (color)
Parametry	Maximum paper format	A4
Parametry	Black print speed	32 str./min
Parametry	Color print speed	32 str./min
Parametry	Black print resolution (dpi)	5760 x 1440
Parametry	Color print resolution (dpi)	5760 x 1440
Parametry	Paper grammage	64–300 g/m²
Parametry	Additional features	display
Parametry	Included consumables	ink (starter)
Parametry	Scanner sensor type	CIS
Parametry	Scanner format	A4
Parametry	Communications	LAN,USB,Wi-Fi
Parametry	Ports	USB typ B,RJ-45
Parametry	Print functions	auto duplex print,borderless printing,CD/DVD Printing
