Oro kompresorius HW, 14 bar, 1120 l/min, alyvos pagrindu

Trumpai apie prekę

Prekė: Oro kompresorius HW, 14 bar, 1120 l/min, alyvos pagrindu. Kategorija: Kompresoriai.

• Gamintojas: Kowal Polska
• Modelis: HW-3090 14 Bar
• Galia: 5.5 kW
• Įtampa: 400 V

• by mounting it on the cylinder, the degree of shutdown on the pressure switch can be set from 4 to 14 bar - depending on your needs
• enlarged valve seats for faster airflow
• original version 2023r on forged connecting rods
• Raised head heat sink
• increased compression ratio to 14 BAR
• steel, inter-valve head gasket is used
• oil lubrication, spray lubrication
• 3 ring pistons with a diameter of 2 x 90 mm + 1 x 65 mm

**** Free LD-100 compressor oil ****

The compressor is air-cooled and oil-lubricated. Designed for painting, pumping, sandblasting, blowing and for all kinds of work with other pneumatic devices.

1. reinforced paw casts
2. metal air filters
3. thicker head pins
4. integrated oil cooler in the compressor body
5. forged connecting rods

• max suction capacity: 1120 L-min
• max working capacity: 900 L-min
• by mounting it on the cylinder, the degree of shutdown on the pressure switch can be set from 4 to 14 bar - depending on your needs
• required compressor rated speed: 800-1000 r/min
• Engine power: 5,5 kw - 7,5 kw
• Suggested cylinder capacity: 200 to 500 L
• max working pressure: 14 bar
• oil bowl capacity: approx. 2 Liters
• Weight: about 40 kg
• Piston diameter: 2 x 90 mm + 1 x 65 mm
• pulley diameter: 35 cm
• Drive: 2 x 17 mm V-belt
• spacing of fixing screws: 25 x 17 cm
• direction of rotation: left (looking from the side of the wheel)
• oil used: compressor LD-100
• 1 replacement after 5 hours, then every 50 hours
• lubrication: splash
• Cylinders: cast iron
• correct oil level: covered 3/4 slide
• Check the oil level before each start. If necessary, supplement its condition.

• 3 piston compressor
• connection pipe with a length of 35cm
• 1'' check valve
• 2 x metal air filter with hepa cartridge
• 1 vent
• 1 infusion stopper
• 2 Liters of oil Ld-100

• pump is much more viable and quieter
• reduced vibration levels
• less heated
• pump operation is neat, even and "pleasant to the ear"
• optimal crankshaft load
• there is no unexpected crank break on the killing piston

• BRAND KowaL - 10 YEARS OF EXPERIENCE IN THE PNEUMATICS INDUSTRY, THOUSANDS OF SATISFIED CUSTOMERS
• CERTIFIED PRODUCT WITH UNINFLATED PARAMETERS
• CERTAINTY OF PROFESSIONAL ADVICE ON PURCHASE AND SERVICE
• WE HAVE OUR OWN SERVICE (AVAILABILITY OF ALL PARTS TO OUR PRODUCTS DURING WARRANTY AND POST-WARRANTY TIME)
• ONLY WITH US THIS CLASS PRODUCT AT SUCH A LOW PRICE WHICH WILL BE USED IN ALL CONDITIONS IN WHICH IT WILL WORK!

Specifications
