Oro kompresorius K23, 100 l, bealyvas, 12 bar, tylus

Trumpai apie prekę

Prekė: Oro kompresorius K23, 100 l, bealyvas, 12 bar, tylus. Kategorija: Kompresoriai.

• Gamintojas: Kowal Polska
• Modelis: SBN 12 Bar SILENT
• Galia: 4.4 kW
• Įtampa: 220 V

• catalog symbol K23
• very quiet - LWA 68 dB !
• factory symbol 2 x SBN-1500

• Height: approx. 80 cm
• length: approx. 90 cm
• Width: approx. 48 cm

The air pump pumps air into a 12 Bar pressure cylinder. The switch (recessor) disconnects the pump when filling a tank of 10 Bar. Thanks to the use of a pump with 20% stock, the unit is not strained, which significantly translates into its service life!

• Our compressor has a cylinder with approval with a real capacity of 100 Liters !
• tank dimensions: diameter 40 cm x length 80 cm
• If you run a company under the supervision of a labour inspectorate, know that we add all documents to each compressor to be reported in UDT

The K23 looks great compared to the competition. His 100L cylinder punching times are:

1. from 0 to 1 bar = 12 s
2. from 0 to 2 bar = 21 s
3. from 0 to 3 bar = 35 s
4. from 0 to 4 bar = 52 s
5. from 0 to 5 bar = 1 min 10 s
6. from 0 to 6 bar = 1 min 30 s
7. from 0 to 7 bar = 1 min 55 s
8. from 0 to 8 bar = 2 min 20 s
9. from 0 to 9 bar = 2 min 50 s
10. from 0 to 10 bar = 3 min 25 s

What distinguishes oil-free air compressors brand blacksmith from competing offers:

• 2 x two-way check valves
• Each piston has a separate filter and its own compressed air outlet
• electromagnetic starter relaxers !
• 2 overcurrent fuses !
• 2 starting capacitors
• Very quiet
• Ecological = oil-free!!! No oil particles in the compressed air produced - the compressor is ideal for work where clean air is required
• 4-piston - four air pumps - built of connecting rod, Teflon ring, cylinder and valve plate, this design guarantees virtually maintenance-free operation of the compressor.
• Enlarged ribbed heads - heat is better dissipated
• Reinforced pistons and low friction piston rings made of high quality materials
• Modern electric motors to prevent excessive vibration of the device - directly on the rotor are placed symmetrically eccentric wheels with bearings and connecting rod
• 2in1 - The compressor is equipped with a separator with a filter and pressure reducer that traps water in the blown air
• Equipped with two readable pressure gauges showing pressure. One of them is combined with a reducer and dehydrator
• Gratis equipped with a quick-connector very resistant to corrosion and mechanical damage directly screwed into the cylinder!
• Homologated cylinder numerically welded by welding machines - perfect quality of welds! Reinforced compressed air cylinder design - additionally protected with 1 anti-corrosion coating.

• suction capacity max: 640 L-min
• max working capacity 1 Bar: 560 L/min
• pressure max: 12 Bar
• working pressure: 10 Bar
• tank: 100 L
• power consumption: 4,4 kw
• compressor rated power: 3 kw
• Security Required: 16 Ampere
• number of working sockets: 3
• 230v/50Hz power supply
• LWA volume with 7m 68 dB!
• duty cycle: s2-15
• Weight: approx. 60 kg
• Piston system: R
• Number of pistons: 4
• pressure reducer: YES
• Dehydrator: YES
• overload protection: YES
• built-in starting relaxer: YES
• induction motor: YES
• certificates: YES
• Declaration of conformity: YES
• built-in safety valve !
• Cylinders: Thermally hardened

• 2 rubberized wheels
• 3 quick-connectors
• built-in dehydrator with reducer
• 4 x air filter with Hepa cartridge
• instruction PL
• integrated 2 fuses

1. Each cylinder has its own air filter
2. very quiet - only 68 dB !
3. Each cylinder has its own air outlet
4. 4 outlet pipes reinforced with steel braid
5. 2 check valves with 2-way air intake!
6. 2 electromagnetic relaxers!
7. 2 starting capacitors.
8. 2 overcurrent fuses

ONLY WITH US!! AN ESSENTIAL ELEMENT IN PAINTING WORKS!

Each compressor in the set has a separator with a dehydrator.

This element captures all impurities from the exhaust air (water, solids).

It has a capacious reservoir and a manual valve for condensate-pollution drain.

• automatic pressure switch
• direct manometer
• Direct quick coupler
• automatic relaxer

• powder coated cylinder
• cycle welded numerically by welding machines - please pay attention to the perfect quality of welds!
• Bottle with homologation !

• Thanks to this solution, you have access to a large and immediate amount of air, unlimited switch or filter.
• It is ideal for blowing, pumping truck tires, or powering large pneumatic wrenches

• BRAND blacksmith - 15 YEARS OF EXPERIENCE IN THE PNEUMATIC INDUSTRY, THOUSANDS OF SATISFIED CUSTOMERS
• CERTIFIED PRODUCT WITH UNINFLATED PARAMETERS
• CERTAINTY OF PROFESSIONAL ADVICE ON PURCHASE AND SERVICE
• WE HAVE OUR OWN SERVICE (AVAILABILITY OF ALL PARTS TO OUR PRODUCTS DURING WARRANTY AND POST-WARRANTY TIME)
• ONLY WITH US THIS CLASS PRODUCT AT SUCH A LOW PRICE WHICH WILL BE USED IN ALL CONDITIONS IN WHICH IT WILL WORK!

Specifications
