Oro šildytuvas su termostatu, PTC, izoliacija

Trumpai apie prekę

Prekė: Oro šildytuvas su termostatu, PTC, izoliacija. Kategorija: Oro šildytuvai.

• Gamintojas: no brand
• Modelis: gh5t6

Car Heater With Constant Temperature PTC Fan Small Room Heating Incubator (24V 300W)

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W

Feature:

1. With insulator on the surface, safe to use, high reliability

2. It heats up quickly, long service life. With mounting holes, easy to install

3. Adopts heat-resistant silicone wire as lead wire, red wire

4. This system is energy efficient, when the heater increases the ambient temperature, the power will be gradually reduced in certain ranges

5. Applicable to radiators, humidifiers, air conditioning and other commonly used appliances. Specification:

Features:

1. With insulator on the surface, safe to use, high reliability.

2. It heats up quickly, long service life. With mounting holes, easy to install.

3. It adopts heat-resistant silicone wire as guide wire, red wire for "+" and black wire for "-".

4. This system is energy efficient, when the heater increases the ambient temperature, the power will be gradually reduced in certain ranges.

5. Applicable to radiators, humidifiers, air conditioning and other commonly used appliances.

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W

Technical data:

Condition: 100% new

Color: Black

Type: #3

Rated Voltage: 24 V

Rated Power: 300 W (15 A)

Mounting hole distance: approx. 87mm / 3,4 quot;

Mounting hole diameter: approx. 4mm/0,16 quot;

Product Size: approx. 60 x 60 x 42 mm / 2,4 inch x 2,4 inch x 1,7 inch

Ambient temperature range: -5 ~ 65 ℃

Package weight: approx. 160g

Quantity: 1 piece

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W

The package includes:

1 x PTC Heater

Instructions for PTC air heater with fan series:

1. When the bare wire protrudes from the heater, the positive and negative electrodes are not distinguished. Please enter the rated voltage and sufficient current.

2. When the bare wire protrudes from the fan, the red is the positive electrode and the black is the negative electrode. Please enter the rated voltage and sufficient current.

3. The heater can be used in a very humid environment. It does not matter if a small amount of water droplets are sprayed on the surface of the radiator, but they can not be submerged in

fluid.

4. The insulation of the black radiator bracket is resistant to high temperatures, but the metal part conducts. During use, attention should be paid to safety.

5. The life of the heater fan is 3~5 years, 20 000~30 000 hours.

6. The heater is equipped with a 230℃ chip. When the fan blows, the surface temperature of the heater is about 100℃. When the fan fails and stops rotating, stop using

heater to avoid potential safety hazards.

7. When the heater is used for the first time, a small amount of smoke or odor may appear, which is caused by an oil stain and the leakage of heat conductive adhesive formed after the aluminum corrugations are pressed. This is normal and will soon disappear.

8. The power of the product depends on the mode of use, heat dissipation conditions, ambient temperature and other factors. The rated power given by us refers to the power measured at

ambient temperature 24℃. Under these conditions, the air temperature at a distance of 5 cm from the outlet is about 50 ℃ Celsius. (when the ambient temperature drops, the heater power will be

increase. )

9. When used in a small enclosed space, after some working time and an increase in ambient temperature near the heater, the energy consumption of the heater will gradually decrease, which is a characteristic feature of the PTC products themselves in terms of energy saving.

10. Safety, stability, energy saving, environmental protection and long service life are the most important advantages of PTC products. With normal use from 5000 to 10000 hours, the power attenuation is about 15%. (Unlimited switching times)

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W

. HEATER AIR HEATER INSULATED THERMOSTATS HEATER PTC 24V300W
