Oro užuolaida Reventon AERIS 100C-1P, 100 cm, su nuotolinio valdymo pultu

Trumpai apie prekę

Prekė: Oro užuolaida Reventon AERIS 100C-1P, 100 cm, su nuotolinio valdymo pultu. Kategorija: Oro užuolaidos.

• Gamintojas: Reventon
• Modelis: AC100C1P
• Galia: 230 W

PACKAGE CONTENTS:

• Curtain cold
• Mounting panel
• Door sensor
• Remote
• Operating instructions with warranty card

This device perfectly protects against losses of decent temperature resulting from alternating opening and closing of the door. Most often, this device is installed in the places of entry/exit from the building, in order to maintain a constant temperature inside the facility and protect against dust and insects coming from the outside. In order to provide a comfortable temperature for customers, the door curtain is installed in restaurants, gyms, as well as hair salons or hotels.

Features of the device:

• high economics of the device,
• effective protection against dust and insects from the outside,
• solid plastic housing,
• remote control, mounting panel and sensor
• door included,
• easy installation,
• contemporary design.

Cold air curtain – basic advantages

Cold air curtain is a solution:

• energy-saving,
• solid (durable metal housing),
• quick and easy to install,
• Mounting panel, remote control and door sensor included

Characteristic

• Durable metal housing, powder coated.
• Available in 3 dimensions: 100, 150, 200 cm.
• Possible operation in continuous mode or using a door sensor.
• Remote control, mounting panel and door sensor included.
• Two-stage fan speed control.

TECHNICAL DATA:

Maximum airflow [m³/h]

II GEAR - 1770

AND GEAR - 1450

Maximum air speed [m/s]

II GEAR - 11

AND GEAR - 9

Curtain range [m]

II RUN - 3

Heater supply voltage [V] /Heater supply frequency [Hz]

230/50

Engine power supply voltage [V] /Engine power frequency [Hz]

230/50

Engine power [W]

II GEAR - 180

AND GEAR - 130

Engine rated current [A]

II GEAR - 0,78

AND GEAR - 0,57

Isolation class / Degree of protection IP [-]

E/IP 20

Net weight [kg]

13,5

Volume [dB]

II GEAR - 56

AND GEAR - 54
