Palydovinis LNB konverteris INVERTO Premium, TWIN, 2 išėjimai, 4K

Trumpai apie prekę

Prekė: Palydovinis LNB konverteris INVERTO Premium, TWIN, 2 išėjimai, 4K. Kategorija: Keitikliai.

• Gamintojas: Inverto
• Modelis: Konwerter twin IDLP-TWL413-PREMU-OPN

LNB TWIN 2-output 4K satellite converter INVERTO Premium

• Support SD and HD resolution
• Support 4k resolution
• Support stereoscopic 3D
• ULTRA LOW NOISE TECHNOLOGY
• own noise 0.2dB
• New model
• 4G
• HDTV, DVB-S2

INVERTO TWIN PREMIUM converter is a product of the well-known Luxembourg company INVERTO, which is a leader among suppliers of converters for the Polish market. The TWIN converter provides a satellite signal for two DVB-S/S2 single-head tuners. or a PVR (double-head) tuner.

LNB supports HD and UHD transmissions and has excellent RF values, very low power consumption and optimal interference suppression of 4G/LTE signals.

Technical data:

• Lower band: 10,7-11,7GHz input
• Lower band: 950-1950MHz output
• Lower oscillator: 9,75GHz
• Upper band: 11,7-12,75GHz input
• Upper band: 1100-2150MHz output
• Upper Oscillator: 10,6GHz
• Own noise: 0,2dB (0,7dB)
• Oscillator temperature drift: +/-3MHz max
• Phase noise: -85dBc/Hz max
• Gain: 55dB min
• Gain characteristics variability: +/-0,75dB/27MHz
• Polarity control: V 11.0~14.0 V
• Polarity control: H 16.0~20.0 V

VSWR 2.5:1:

• Current consumption: 180mA max @11~20V
• Output Impedance: 75Ohm
• Operating temperature: -30...+60C
• Neck Width: 40mm
• Connector: F
• Item Weight: 0,300 kg
