Prekė: Palydovinis LNB WideBand konverteris SMART Titanium TWT H+V. Kategorija: Keitikliai.
- Gamintojas: Smart
- Modelis: Titanium
The subject of sale is:
LNBWB-TWT; LNB WideBand SMART Titanium TWT H+V
Quatro type converter operating in WideBand technology dedicated for installations operating in the WideBand system with programmable multiswitches.
LNB differs from standard quattro converters in that it has two H+V signal outputs instead of four, which is why an installation based on one satellite requires only two satellite wires conducted from LNB to multiswitch.
Technical data of LNB Smart Titanium TWT:
Input frequency range: 10.7 - 12.75 GHzOutput frequency range:
vertical: 300 - 2350 MHzlevels: 300 - 2350 MHzNoise phase frequency: -50dBc/Hz @ 1KHz (Max. )-75dBc/Hz @ 10KHz (Max. )-95dBc/Hz @ 100KHz (Max. )Noise Ratio: 0.1 dB (Typ. )Conversion Gain: 55 dBVariability Gain: 5 dB (max.) @ full bandProfit in 26 MHz: +/-0.5dB (Typ. )Image rejection: 40 dB (Min. )Power supply: 10-14V Connector type at output: 75 OHMS FZ female connector Operating temperature range: -40°C - +60°C
Examples of installation solution (on the example of DUR-Line converter):
Specifications
| Group | Name | Value |
|---|---|---|
| Parametry | Condition | new |
| Parametry | Invoice | With VAT invoice |
| Parametry | Manufacturer code | Titanium |
| Parametry | Type | Other |
| Parametry | Brand | Smart |
| Parametry | Model | Titanium |
| Parametry | Handle diameter | 40 mm |
| Parametry | Product weight | 500 g |
| Parametry | EAN (GTIN) | 4056742005540 |
| Parametry | Certificates of conformity | CE |
