Plieninė palydovinė antena FAMAVAL TRX-EL 85 cm, grafito spalvos, HD, 4K

Trumpai apie prekę

Prekė: Plieninė palydovinė antena FAMAVAL TRX-EL 85 cm, grafito spalvos, HD, 4K. Kategorija: Antenos.

• Gamintojas: Famaval
• Modelis: TRX-EL 90

Graphite

The FAMAVAL 90 TRX-EL steel satellite antenna with dimensions of 90,5 cm x 83,4 cm is characterized by excellent reception parameters. The antenna is made of steel in advanced technology, which makes it the highest resistance to weather conditions.

TRX EL series satellite bowls are manufactured according to the quality standards of the Portuguese company Famaval. The diameter of the canopy allows seamless reception of channels in HD quality from one or two satellite positions (squinting system). In order to install the second converter, use the handle of the second FAMAVAL converter or the universal handle of the second converter.

The antenna is designed for small and medium-sized television collective installations implemented in single-family buildings and wherever a high level and good signal quality are necessary at the entrance of the installation.

Technical data:

• Name: TRX-EL 85
• Type: antenna
• Purpose: satellite
• Type: offset
• Brand: FAMAVAL
• Color: dark / graphite
• Floodlight material: galvanized steel, powder coated
• Floodlight thickness [mm]: 0,7
• Floodlight dimensions [mm]: 850x805
• Profit for 11.7 GHz [dBi]: 37,6
• Profit for 12.7 GHz [dBi]: 38.7
• Focal f [mm]: 515
• Angle of the facade [degrees]: 0...59
• F/D ratio: 0.64
• Converter diameter [mm]: 40
• - Subwoofer mast diameter [mm]: 60
• External dimensions [mm]: 905x834
• Mass [kg]: 5,5
