Plytelių pjaustyklė Gresu 120 cm, profesionali

Trumpai apie prekę

Prekė: Plytelių pjaustyklė Gresu 120 cm, profesionali. Kategorija: Plytelių pjaustytuvai.

• Gamintojas: Fortum
• Modelis: 4770848

Key information

The professional hand cutter Fortum Professional 4770848 is designed for precise cutting of glaze, stoneware and ceramic tiles up to 1200 mm in length. Thanks to the guide with 24 bearings, folding base and adjustable head, it ensures smooth knife handling and high comfort of work both during renovations and professional glazing work.

The most important features

• Maximum cutting length: 1200 mm
• Designed for materials with a thickness of 6 to 18 mm
• Professional head guided on 24 NSK bearings
• Very smooth movement of the cutting mechanism
• Folding base with transport wheels
• Built-in handle for easy carrying
• Two aluminium side rulers with a length of 590 mm
• Possibility of mounting a guide laser 4770840A
• Cutting wheel 22 × 6 × 6 mm
• Stable construction with a weight of 19 kg
• Spare cutting wheel available 4770805

The biggest advantages of the product

⚙ Professional mechanism with 24 bearings

The guide unit is equipped with 24 NSK bearings, which are responsible for extremely smooth head movement. This solution increases steering precision and reduces resistance when cutting tiles.

📏 Cutting tiles up to 1200 mm

The cutter allows convenient cutting of large tile formats up to 1200 mm. It works well when making floors, wall cladding and modern arrangements using large-format stoneware.

🏗 Folding base with transport

A solid base can be quickly assembled when the job is done. Built-in transport wheels and handle make it easy to move the device between workstations.

📐 Aluminium measuring guides

Two folding rulers made of lightweight aluminum have a clear graduation. They allow you to quickly set the dimension and make repetitive cuts without additional measuring of the material.

🎯 Possibility of laser mounting

The model was adapted to install an optional Fortum 4770840A guide laser. The solution makes it easier to control the cutting line and increases the comfort of precise work.

🛠 Durable construction for intensive work

The massive frame and stable base ensure proper support of the workpiece. The design has been developed for frequent use during glazing work.

Technical specification

• Type: Handheld tile cutter
• Application: Cutting of glaze, stoneware and ceramic tiles
• Material: Steel construction with aluminium elements
• Maximum cutting length: 1200 mm
• Thickness of cut material: 6 – 18 mm
• Number of guide bearings: 24 (NSK)
• Cutting wheel: 22 × 6 × 6 mm
• Spare wheel: 4770805
• Side rulers: 2 × 590 mm
• Dimensions of the unfolded base: 1490 × 690 mm
• Possibility of laser mounting: Yes (4770840A)
• Weight: 19 kg
• Brand: Fortum Professional
• Manufacturer code: 4770848
• EAN code: 8595703611100

Professional driving accuracy

The most important element of the device is a professional head moving on 24 NSK bearings. This solution ensures a very smooth movement on the guide, reduces vibrations and facilitates simple and repetitive cuts.

Suitable for large formats

The maximum cutting length of 1200 mm allows you to process popular tile formats used in modern construction. The stable design makes it easy to maintain proper accuracy even with larger components.

Measuring rulers with adjustment

Two aluminium rulers with a length of 590 mm allow convenient setting of the cutting dimension. The clear graduation helps to make serial cuts with high repeatability.

Sturdy steel handle

The handle is made of one reinforced block of high quality steel, thanks to which it is characterized by very high mechanical strength. This design ensures stable force transfer during cutting and breaking of tiles and reduces the risk of deformation even during intensive use.

One-piece construction increases the durability of the entire mechanism and allows you to maintain high precision of work for a long time.

Strong foot for breaking tiles

The breaking foot is made of one piece of durable, high-quality steel, which ensures even pressure transfer to the plate when breaking it.

Robust construction increases the breaking efficiency after the incision and affects the durability of the entire mechanism, especially during regular work with ceramic tiles and stoneware.

Stable folding base

The base is equipped with folding supports that increase the working surface during cutting. Once finished, the device can be quickly folded and the transport wheels make it easy to move around.

Durable cutting wheel

The device uses a cutting wheel 22 × 6 × 6 mm, designed for effective cutting of tiles. The manufacturer also provided for the possibility of using the original spare wheel 4770805, which facilitates subsequent operation.

Application

The cutter is designed for:

• cutting of stoneware tiles
• cutting glaze
• cutting ceramic tiles
• execution of wall cladding
• laying of stoneware floors
• renovation works
• professional glazing work
• construction and finishing applications

Possibility of expansion with laser

The cutter has been prepared for the installation of an optional guide laser with catalog number 4770840A. Thanks to this, the user can further increase the convenience of determining the cutting line.

It is possible to buy LASER for models 4770840, 4770841, 4770842 4770848

❗ NOTE :The laser is not part of the set, it can optionally be purchased at our auction❗

FAQ – FREQUENTLY ASKED QUESTIONS

❓ Does the cutter allow cutting tiles with a length of 120 cm?

✅ Yes, maximum cutting length is 1200 mm.

❓ Is the machine suitable for cutting stoneware?

✅ Yes, cutter is designed for cutting stoneware, glaze and ceramic tiles.

❓ Can 18 mm thick tiles be cut?

✅ Yes, the manufacturer specifies the thickness range of the cut materials at 6 to 18 mm.

❓ Does the head have bearings?

✅ Yes, 24 NSK bearings are used to ensure smooth movement.

❓ Is it possible to install a laser?

✅ Yes, the device is adapted to mount the Fortum 4770840A laser.

❓ Does the cutter have a folding base?

✅ Yes, the base is foldable and equipped with transport wheels.

❓ What cutting wheel was used in the device?

The cutter uses a cutting wheel with dimensions 22 × 6 × 6 mm.

❓ Is there a spare cutting wheel available?

✅ Yes, the manufacturer offers an original spare wheel with the catalog number 4770805.

✅ DIFFERENCES IN THE NEW MODEL :✅

1. Better build quality - the materials used to make the new Fortum model have been improved. More aluminum and better quality steel used
2. Less weight - by using more aluminum and using better quality steel, it has now been possible to reduce the weight of the razor weighs 19 kg instead of 23 kg
3. Smaller base - the base has been slimmed down, which allows for even better breaking of tiles reduces the size of the device itself
4. Handle and foot for breaking more precise and solid - foot and handle have been improved and their structures have been changed, their dimensions have been increased, which allows for much more precise movements in cutting and breaking tiles
5. Side rails with a precise ruler made of aluminum - Side profiles are made of high quality aluminum on which a very accurate ruler has been laser applied. Now the dimensions are even more precise

The FORTUM brand is the highest professional line of our Czech tools. Quality is the most important parameter here. The products have proven themselves over the years of the brand’s existence in many European markets in the toughest working conditions. FORTUM tools have been tested by professionals.
