Plytelių pjaustyklė rankinė, 80 cm, tinka akmens masės ir keraminėms plytelėms, apvaliam pjovimui

Trumpai apie prekę

Prekė: Plytelių pjaustyklė rankinė, 80 cm, tinka akmens masės ir keraminėms plytelėms, apvaliam pjovimui. Kategorija: Plytelių pjaustytuvai.

• Gamintojas: Delphi tools
• Modelis: Maszyna do Cięcia z Laserem 800 mm Ręczna

This Manual Tile Cutter with an 80 cm cutting length, featuring a laser cutting guide, is designed for precise and repeatable tile work. It's ideal for both home renovations and professional use.

➡️Large Cutting Length (80 cm) - Allows for comfortable work with large-format tiles.

➡️Precise Cutting with Laser Guide - The laser cutting guide allows for perfect tile alignment and minimizes the risk of errors.

➡️Solid, Dual-Rail Construction - Ensures stability, smooth carriage movement, and long tool life.

➡️High Breaking Force - Makes it easy to break even hard porcelain tiles.

➡️Accurate Scale and Stop - Allows for quick execution of repetitive and angled cuts.

➡️Ergonomic Handle - A comfortable grip increases control over the tool and working comfort.

✳ Set includes:

• 1x Delphi tools tile cutter
• 1x Cutting wheel (mounted in the cutter)
• 2x Plastic Stand
• 1x Limiter with measuring cup
• 1x Angle limiter
• 1x User Manual

✳ Specification:

• Maximum cutting length: 800 mm
• Cutting thickness: 16mm
• Guide type: Double steel reinforced guides
• Cutting type: Straight and angled
• Cutting mechanism: Trolley with ball bearings - smooth movement
• Cutting wheel material: Tungsten Carbide
• Diameter of cutting wheel: Ø22 x Ø6 x 6 mm
• Measuring guides: Aluminum arm with precise graduation
• Built-in laser: YES
• Tile breaking system: Upper pressure with rubber cushioning
• Purpose: For cutting ceramic tiles, stoneware, terracotta, glaze

✳ Cutting large format tiles - up to 80 mm!

The cutter is perfect for working with large format tiles - its working length of up to 80 mm allows for precise cutting of large tiles without having to rotate them or move them repeatedly.

✳ Interchangeable cutting wheel

The cutter is equipped with a replaceable cutting wheel, which significantly increases its service life and functionality. The blade made of hard tungsten carbide (Tungsten Carbide) guarantees clean, precise cuts of even the toughest ceramic or stoneware tiles.

Thanks to the use of ball bearing, the wheel moves smoothly and stably on the guide, minimizing resistance and the risk of tile breakage. The ability to quickly replace it ensures that the tool is always ready to work - just mount a new element to restore full efficiency and accuracy of cutting.

It is a practical solution for professionals who value reliability, economy and precision.

Dimensions of the cutting wheel:

• Ø22 x Ø6 x 6 mm

✳ Laser cutting gauge

Laser cutting indicator is an extremely practical convenience used in this cutter, which significantly increases accuracy and convenience.

• It sets the perfect cutting line, so you can precisely position the tile without having to mark it first.
• It facilitates fast and even handling of the cutting trolley, even with very long tiles.
• Especially useful for large format elements, where every millimeter of deviation counts.
• The laser is visible even in brighter rooms, which increases the comfort of work inside and on the construction site.

It is a solution that raises the standard of the cutter, allowing you to make cuts with the highest precision - quickly, without corrections and without material loss.

✳ Manual Breaker

• Manual breaking mechanism

The breaker works on the principle of a lever - after cutting the tile with a blade, the user leaves the handle, and the mechanical pressure separates the material along the marked cutting line.

• Reinforced cutting arm

The arm is made of durable metal for durability and rigidity during operation. With its ergonomic handle, the pressure force distributes evenly, allowing you to break tiles accurately and effortlessly.

• Stable downforce

Precise handling and parallel breaker pressure minimize the risk of tile shifting or damage, ensuring clean breaking lines even with harder materials such as stoneware.

• Security and control

Thanks to its well-thought-out design and ease of use, the breaker allows you to safely cut even large formats, without the need for excessive force or specialized tools.

✳ Scale limiter and angle limiter

Restrictor with graduation:

• It allows you to accurately set the desired cutting dimension, allowing you to quickly and repetitively cut tiles of the same width.
• The easy-to-read measuring cup makes it easy to measure without the need for additional measuring tools.
• Made of durable material, guarantees stability during cutting.

Angle limiter:

• It allows you to make cuts from different angles - ideal for bevels, corners and laying herringbone tiles or karo pattern.
• It features a precise angle graduation that makes it easy to set the exact cutting angle.
• Adjustable with a knob, allowing you to quickly adjust the setting to suit your needs.

✳ Application:

Cutting ceramic and stoneware tiles

• It is perfect for working with floor, wall and large format tiles - both in home renovations and professional glazing works.

Simple and serial cuts

• Thanks to the graduated stop, it is possible to quickly, repetitively cut tiles to the same size - e.g. when finishing rooms with many identical elements.

Cutting at an angle

• The angle limiter allows precise cutting at a given angle - ideal for corners, laying tiles diagonally or in a karo system.

Professional and hobby applications

• The tool is suitable for both tilers and DIYers performing renovations on their own.

Gallery

Delphi Tools is a brand created for people involved in DIY both in their free time and on a daily basis. We focus on comfort in the use of equipment, which in addition to interesting design is characterized by high durability. For many years, we have been trying to provide you with tools that will facilitate repairs and save time, and also meet the highest quality standards and exceed the expectations of users.
