Plytelių pjaustyklė su lazeriu GEKO, 1200 mm

Trumpai apie prekę

Prekė: Plytelių pjaustyklė su lazeriu GEKO, 1200 mm. Kategorija: Plytelių pjaustytuvai.

• Gamintojas: Geko
• Modelis: G30117

Characteristics

The GEKO manual tile cutter is a professional tool dedicated to precise cutting of ceramic tiles. Featuring a sturdy metal frame, this mobile design offers not only superior performance but also ease of transport and portability with its comfortable handle and two wheels.

One of the key elements of this cutter is the laser pointer, which significantly increases the accuracy of cutting. The cutting wheel made of tungsten carbide ensures high cutting quality and tool durability. With its optimized thickness and design dimensions, the tool is perfect for cutting tiles with a thickness range of 4mm to 16mm with precision.

The cutter allows straight cutting with a cutting length of up to 1200 mm, as well as diagonal cutting with a length of up to 850 mm.

With a cutting length of 1200 mm and a breaking force of 1000 kg, this cutter is designed for demanding applications.

In addition, two side supports with a length of 28 cm, covered with foam, provide stability during cutting. The cutter is also equipped with a side positioning support for diagonal cutting, which increases the range of applications of this professional ceramic tile processing tool.

• The sturdy metal frame ensures stability and durability during use.
• The laser pointer allows for precise positioning and cutting, increasing the accuracy of the process.
• It is perfect for cutting tiles of various thicknesses, covering a range from 4 mm to 16 mm.
• The cutting wheel made of tungsten carbide ensures durability and precision of cutting, which is important for machining materials of different hardness.
• The cutting length of 1200 mm makes the tool effective in machining larger tiles.
• Two side supports with a length of 28 cm, covered with foam, provide stability during operation.
• The adjustable positioning side support allows diagonal cutting, provides additional support, and the ruler with a scale of up to 63,5 cm makes it easy to adjust precisely.
• The mobile design makes it easy to move the tool between workspaces.
• Handle with rubber cover provides ergonomic handling.
• The presence of two wheels allows convenient transport, which is important in professional conditions.
• The bearing handle enhances the comfort of use, allowing for smooth and precise maneuvering of the tool.

Technical data

• Maximum cutting length (mm): 1200
• Maximum diagonal cutting length(mm): 850
• Supported tile thicknesses (mm): 4 - 16
• Breaking force (kg): 1000
• Cutting wheel size (mm): 22x6x6
• Weight (kg): 17
• Laser Pointer: Yes
